Viewing angle, horizontal:
Maximum horizontal angle at which a display can be viewed with acceptable visual performance.
-
103 °
-
Viewing angle, vertical:
Maximum vertical angle at which a display can be viewed with acceptable visual performance.
-
54.8 °
-
Megapixel (approx.):
The number (in millions) of light-sensitive picture elements known as pixels actually used by the camera's image sensor (CCD) to record light, and which are reflected to the final number of recorded pixels stored on the memory card.
-
4 MP
-
Supported network protocols:
Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
-
FTP/TFTP HTTP/HTTPS TR-069SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS RTP/RTCP/SRTP STUN DHCP IPv6 PPPoE L2TP OpenVPN SNTP
-
Operating relative humidity (H-H):
-
10 - 95
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-40 - 70
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-40 - 70
-
Height:
The measurement of the product from head to foot or from base to top.
-
205 mm
-
Sensor type:
A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device.
-
CMOS
-
Optical sensor size:
Optical sensors are electronic detectors that convert light, or a change in light, into an electronic signal. They are used in many industrial and consumer applications e.g. lamps that turn on automatically in response to darkness. Optical sensors come in many sizes.
-
25.4 / 2.9
-
Wall mountable:
The product can be mounted on (attached to ) a wall.
-
Yes
-
Width:
The measurement or extent of something from side to side.
-
120 mm
-
Depth:
The distance from the front to the back of something.
-
54.5 mm
-
Connectivity technology:
The technology that enables connectivity of the device, e.g. wired or wireless.
-
Wired
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Silver
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.3at
-
Voice codecs:
-
G.711a
-
Camera included:
This product includes a camera.
-
Yes
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
1
-
Power over Ethernet (PoE):
The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
-
Yes
-
Web-based management:
Using a website/web application to manage something.
-
Yes
-
Ethernet LAN data rates:
The different speed levels of the Ethernet LAN connection.
-
10, 100
-
Package depth:
The distance from the front to the back of the packaging.
-
80 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
286 mm
-
Package width:
The distance from one side of the packaging to the other.
-
168 mm
-
Supported video modes:
The video modes that can be displayed by the device.
-
720p, 1080p
-
Video formats supported:
The type of video formats that can be used by this device.
-
H.264
-
Syslog:
-
Yes
-
RS-485 ports:
-
1
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP66
-
IK code:
-
IK10
-
Viewing angle, diagonal:
-
122 °
-
Quantity per pack:
-
1 pc(s)
-
Memory card slot:
-
Yes
-
Outdoor unit included:
-
Yes
