F&F AS-214 Staircase Timer 24V 16A DIN Rail Mount 1-Module IP40

The F&F AS-214 is a professional-grade staircase timer engineered for reliable lighting control in 24V electrical systems. Designed for efficiency and durability, this device allows for the automatic deactivation of lighting after a pre-defined time interval, ensuring that lights in common areas are only active when necessary. Its compact 1-module design is optimized for installation on standard DIN rails, making it an ideal solution for modern electrical distribution boards.

Advantages

This staircase timer offers a robust 16A switching capacity, allowing it to handle significant lighting loads with ease. By automating the lighting cycle, it significantly reduces energy consumption and extends the lifespan of light sources. The device is built to high standards, ensuring consistent performance in various indoor environments. Its compact form factor saves valuable space in electrical cabinets, while the straightforward installation process simplifies integration into both new and existing electrical infrastructures.

Suitable for

• Stairwell lighting control
• Corridor and hallway illumination
• Automated lighting in public buildings
• Energy-efficient lighting management in residential complexes

This device is not suitable for high-voltage AC systems, as it is specifically engineered for 24V applications. It should not be installed in environments with high humidity or exposure to dust, as the IP40 rating does not provide protection against water ingress or fine particulate matter.

Key specifications

• Supply voltage: 24V
• Maximum switching current: 16A
• Mounting type: DIN rail (TH-35)
• Housing width: 1 module (18 mm)
• Protection rating: IP40

To use the F&F AS-214, mount the unit onto a standard DIN rail within your distribution board. Connect the 24V power supply and the lighting circuit according to the provided wiring diagram. Once installed, set the desired time interval using the adjustment dial on the front of the device. The timer will automatically trigger the lighting circuit upon receiving a signal from a push-button and will deactivate it once the set time has elapsed.

What to consider before purchase

• Ensure your lighting system operates on a 24V power supply
• Verify that the total load of the lighting circuit does not exceed 16A
• Check available space on the DIN rail within your electrical cabinet
• Confirm that the installation environment meets the IP40 protection requirements

Usage recommendations

For optimal performance and safety, ensure that all electrical connections are tightened securely and that the device is installed by a qualified professional in accordance with local electrical regulations.
