Time relay module Finder 86.30 series 86.30.0.024.0000 12–24 V DC/AC, multifunction time switch

Finder 86.30.0.024.0000 is a multifunction time relay module from Finder's 86.30 series designed for accurate switching and timing control in low-voltage installations. The device accepts a 12–24 V DC/AC supply and offers a range of programmable time functions including pulse, interval and delayed switching modes. It is intended for mounting within control panels or enclosures and integrates with control circuits to automate sequential operations and timed control tasks.

Advantages

The module provides multiple timing functions within a compact housing, enabling versatile use without the need for multiple separate timers. Its low-voltage supply compatibility (12–24 V DC/AC) allows flexible integration into DC and AC control systems. The unit is built for panel mounting and designed to deliver repeatable and precise timing performance for automation tasks, lighting control and HVAC sequences.

Suitable for

• Control panels and DIN-rail enclosures requiring timed switching
• Lighting circuits with delay or pulse control needs
• HVAC systems for timed fan, pump or damper control
• Industrial automation sequences and machine control
• Timed signalling and process control in commercial installations

Key specifications

• Supply voltage range: 12–24 V DC/AC
• Multifunction timing modes: pulse, interval, delayed switching (selectable)
• Panel mounting form factor suitable for control enclosures
• Designed for repeatable timing control in automation circuits

How to use

Install the timer module in a suitable control panel or enclosure following applicable electrical installation standards. Connect the 12–24 V DC or AC power supply to the designated input terminals and wire the output contacts into the control circuit you wish to time. Select the required timing function and set the time range according to the application. Verify correct operation by running test cycles and adjust settings as needed to achieve the desired switching behaviour.

Usage recommendations

Use the module within its rated supply voltage range and in environments that comply with the equipment’s intended mounting and protection ratings. For reliable operation, install in a clean, dry panel with appropriate wiring practices and overload protection on associated circuits. When integrating into safety-related applications, follow relevant regulations and include required interlocks or redundancy.
