Metal Cutting Brush Holder GEKO CG80715-E for 350 mm Cutting Machines

Replacement brush holder for metal cutting machines by GEKO, designed specifically for machines that use 350 mm cutting wheels. This component provides the mechanical mounting and electrical contact points for carbon motor brushes, maintaining correct brush alignment and ensuring consistent current transfer to the rotor. The GEKO CG80715-E brush holder is intended for maintenance and repair tasks where restoring brush seating and reliable motor operation is required.

Advantages

The brush holder restores stable brush positioning and reliable electrical contact, which reduces sparking and improves motor performance compared to worn or damaged holders. Constructed to fit standard brush assemblies used in 350 mm metal cutting saws, it facilitates straightforward replacement and helps prolong the service life of the motor. The design supports secure mounting and consistent pressure on the brushes to maintain effective commutation under load.

Suitable for

• Repair and maintenance of 350 mm metal cutting saws
• Replacing worn or damaged brush holders to reduce motor sparking
• Workshops and service centers performing routine motor maintenance
• Restoring proper brush alignment after disassembly or accidental damage

Key specifications

• Compatibility: designed for metal cutting machines with 350 mm cutting wheels
• Function: mounting and electrical contact point for motor carbon brushes
• Material: metal and insulating components suitable for electrical contact and mechanical stability
• Fitment: supports standard brush dimensions used in 350 mm cutting saw motors
• Mounting: prepared for direct replacement in compatible motor housings

How to use

Before installation, disconnect the machine from the power supply and remove the cutting wheel guard according to the machine manufacturer’s instructions. Access the motor brush area and remove the old brush holder by detaching mounting screws and electrical connectors. Install the replacement holder in the same position, secure mounting hardware, and reconnect electrical contacts ensuring correct polarity and firm connections. Insert compatible carbon brushes and verify they move freely within the holder and make consistent contact with the commutator. Reassemble the protective covers and perform a brief functional test at low load to confirm proper operation and absence of excessive sparking.

Usage recommendations

Use only carbon brushes that match the motor manufacturer’s specified dimensions and material. Inspect brush springs and commutator condition when replacing the holder; replace excessively worn brushes or service the commutator to ensure optimal performance. Follow safety procedures when working on powered equipment and verify secure mounting and electrical connections before normal operation.
