Gimex gauge plate 1.15 mm class 1 model 319.0115.1

Gimex gauge plate 1.15 mm class 1 model 319.0115.1 is a precision reference plate with a nominal thickness of 1.15 mm and accuracy class 1. It is designed for use as a measuring standard, shim, or reference surface in calibration and inspection workflows where defined gap or thickness control is required. The plate’s flatness and certified tolerance make it suitable for workshop use, quality control benches, and assembly processes that require repeatable thickness checks or alignment aids.

Advantages

The gauge plate provides a stable, accurately sized reference that simplifies thickness verification and gap setting. Manufactured to a strict accuracy class, it reduces measurement uncertainty when used alongside calipers, micrometers, feeler gauges, or dial indicators. Its compact, rigid form factor is convenient for repeated handling and placement in measurement setups and assembly fixtures.

Suitable for

• Thickness verification and calibration of measuring tools
• Use as a shim or spacer in assembly and alignment tasks
• Reference surface for inspection benches and quality control
• Workshop measurement setups and jigs

Key specifications

• Nominal thickness: 1.15 mm
• Accuracy class: 1 (precision reference)
• Form: flat plate suitable for use as a reference or shim
• Intended use: calibration, thickness verification, gap control, assembly aid

How to use

Place the gauge plate on a clean, stable measurement surface or directly between parts to set a defined gap. When verifying thickness of measuring instruments, ensure contact surfaces are clean and free of debris, position the instrument per its operating procedure, and compare readings against the plate’s nominal thickness. For shimming or alignment, insert the plate between mating components and secure as required, then perform final measurements to confirm the desired spacing.

Usage recommendations

Handle the gauge plate with care to avoid scratches or contamination; store it in a protective case or wrapped in a clean, lint-free cloth when not in use. Clean contact surfaces with a soft, non-abrasive cloth and, if needed, a mild solvent compatible with the plate material. Use in temperature-stable environments to minimize dimensional variation during precision measurements.
