Diamond Cutting Disc 115x22.2 mm Turbo Super Thin — GRAPHITE 57H620

Diamond cutting disc 115x22.2 mm Turbo Super Thin by GRAPHITE is a turbo-segmented disc designed for fast, precise cutting of hard construction materials. With a 115 mm diameter and a 22.2 mm bore, this super thin blade minimises material loss while delivering efficient chip evacuation thanks to the turbo rim design. It is intended for use with angle grinders and similar portable cutting tools for installation, renovation and general building tasks where fast, accurate cuts are required.

Advantages

The turbo segmented rim accelerates cutting speed and improves debris removal, reducing friction and heat build-up during operation. The super thin core reduces the width of the cut for less waste and finer finishing of edges. The disc construction balances cutting performance with durability to provide reliable operation on concrete, masonry, ceramic tiles and natural stone when used according to recommended safety and operating parameters.

Suitable for

• Cutting concrete and reinforced concrete (non-structural light cuts)
• Cutting masonry blocks, bricks and mortar joints
• Straight and curved cuts in ceramic and porcelain tiles
• Shaping and trimming natural stone such as granite and sandstone
• On-site renovation and installation work with angle grinders

Key specifications

• Diameter: 115 mm
• Bore (arbor) diameter: 22.2 mm
• Segment type: turbo segmented rim
• Blade profile: super thin cutting core
• Primary materials: diamond abrasive segments bonded to a steel core
• Typical tool compatibility: 115 mm angle grinders and handheld cutters with 22.2 mm arbor

How to use

Mount the disc on a compatible 115 mm angle grinder with a 22.2 mm arbor, ensuring the disc direction arrow matches the tool rotation. Securely tighten the flange according to the tool manufacturer's instructions. When cutting, use steady, even feed pressure and avoid forcing the disc; allow the diamond segments to do the work. For best results on masonry and concrete, use intermittent cutting and allow the disc to cool between passes. Always use appropriate personal protective equipment and follow the grinder and disc safety recommendations.

Usage recommendations

Use water cooling only if the disc and the specific tool support wet cutting; otherwise operate dry with proper dust extraction. Avoid lateral or twisting forces on the disc; maintain full-face contact with the material and replace the disc if segments become damaged or excessively worn. Store the disc flat in a dry environment to prevent warping.
