LED panel Heda HPB4060UGRT3 — 40W, CCT 3000K/4000K/6000K, 4400 lm, UGR, IP20

Flat LED panel Heda HPB4060UGRT3 is a 40W recessed/surface-mount luminaire designed for indoor commercial spaces. It delivers 4400 lm with a selectable correlated color temperature (CCT) of 3000K, 4000K or 6000K to match different visual requirements. The panel includes UGR glare control to reduce discomfort and visual fatigue, and IP20 protection suitable for typical interior environments such as offices, classrooms and retail areas.

Advantages

This LED panel provides energy-efficient lighting with a high luminous flux relative to its power consumption, enabling lower operational costs compared to traditional fluorescent fixtures. The selectable CCT allows quick adaptation of light appearance from warm to neutral to cool white without changing the fixture. UGR glare control improves visual comfort for tasks that require prolonged attention and reduces screen reflections in work environments. The slim flat profile supports recessed and surface mounting options and integrates into suspended ceilings or visible installations where a low-profile design is required.

Suitable for

• Open-plan and cellular offices where uniform, low-glare illumination is needed
• Educational facilities such as classrooms and lecture halls
• Retail shops and showrooms requiring consistent color rendering and adjustable CCT
• Healthcare administrative areas, corridors and waiting rooms

Key specifications

• Rated power: 40 W
• Luminous flux: 4400 lm
• Selectable color temperature: 3000 K / 4000 K / 6000 K
• Glare control: UGR-compliant design for reduced glare
• Protection rating: IP20 (indoor use)
• Form factor: flat panel suitable for recessed or surface mounting

How to use

Install the LED panel according to the mounting method chosen (recessed into a compatible suspended ceiling or mounted to a flat surface) and follow local electrical codes. Connect to a compatible mains supply using the supplied driver or approved wiring, ensuring power is disconnected during installation. Select the desired color temperature using the panel's built-in CCT selector or switch as provided by the manufacturer. After installation, verify uniform illumination and check that UGR performance meets the visual comfort requirements of the space.

Usage recommendations

Use the 3000K setting for spaces where warmer, relaxed lighting is preferred; 4000K for general-purpose office and retail environments; and 6000K for task-focused or utility areas where cooler, high-contrast light aids visibility. For best results in workplaces with screens, position panels to minimize direct reflections and maintain recommended mounting heights to preserve UGR benefits. Ensure adequate ventilation around the driver and avoid exposure to moisture beyond IP20 conditions.
