Viewing angle, horizontal:
Maximum horizontal angle at which a display can be viewed with acceptable visual performance.
-
124 °
-
Viewing angle, vertical:
Maximum vertical angle at which a display can be viewed with acceptable visual performance.
-
75 °
-
Colour:
The main colour of the product.
-
Yes
-
Megapixel (approx.):
The number (in millions) of light-sensitive picture elements known as pixels actually used by the camera's image sensor (CCD) to record light, and which are reflected to the final number of recorded pixels stored on the memory card.
-
2 MP
-
Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.35 kg
-
Wi-Fi standards:
The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.
-
802.11b, 802.11g, Wi-Fi 4 (802.11n)
-
Power consumption (typical):
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
-
10 W
-
Supported network protocols:
Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
-
TCP/IP, RSTP
-
Operating relative humidity (H-H):
-
10 - 95
-
Package weight:
Weight of the packaged product.
-
687 g
-
AC adapter output voltage:
-
12
-
Built-in microphone:
Microphone that is found inside the product.
-
Yes
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-40 - 53
-
Height:
The measurement of the product from head to foot or from base to top.
-
91 mm
-
LED indicators:
-
Y
-
Wall mountable:
The product can be mounted on (attached to ) a wall.
-
Yes
-
Width:
The measurement or extent of something from side to side.
-
174 mm
-
Depth:
The distance from the front to the back of something.
-
29 mm
-
Connectivity technology:
The technology that enables connectivity of the device, e.g. wired or wireless.
-
Wired
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black, Grey
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.3af
-
Speakerphone:
Device has a microphone and loudspeaker provided separately from those in the handset. This device allows multiple persons to participate in a conversation. The loudspeaker broadcasts the voice or voices of those on the other end of the telephone line, while the microphone captures all voices of those using the speakerphone.
-
Yes
-
Voice codecs:
-
G.711a, G.711u
-
LED type:
-
IR
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
1
-
Built-in speaker(s):
The device contains speaker(s) to produce sound.
-
Yes
-
Proper use:
The intended application of the product.
-
Outdoor
-
Power over Ethernet (PoE):
The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
-
Yes
-
Operating system installed:
Type of operating system on a device e.g. IOS on Apple devices, Android for mobile devices.
-
Linux
-
Wi-Fi:
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
-
Yes
-
Placement supported:
Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.
-
Vertical
-
Ethernet LAN data rates:
The different speed levels of the Ethernet LAN connection.
-
10, 100
-
Package depth:
The distance from the front to the back of the packaging.
-
120 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
220 mm
-
Package width:
The distance from one side of the packaging to the other.
-
140 mm
-
Supported video modes:
The video modes that can be displayed by the device.
-
720p, 1080p
-
Night vision:
Night vision is technology which allows you to see in low light conditions.
-
Yes
-
Echo cancellation:
-
Yes
-
Ethernet interface type:
-
Fast Ethernet
-
Maximum video resolution:
This is the maximum resolution of video images. Resolution is a measure of the degree of detail visible.
-
1920 x 1080
-
Maximum frame rate:
This is the maximum frame rate, also known as frame frequency and frames per second (FPS). It is the frequency (rate) at which an imaging device produces unique consecutive images called frames. The term applies equally well to film and video cameras, computer graphics, and motion capture systems. Frame rate is most often expressed in frames per second (FPS) and is also expressed in progressive scan monitors as hertz (Hz).
-
30 fps
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP65
-
Number of buttons:
The quantity of buttons, which are small device on a piece of electrical or electronic equipment which are pressed to operate it.
-
4 buttons
-
Night vision distance:
-
3
-
Streaming capability:
-
Yes
-
IK code:
-
IK08
-
Motion detection function:
-
Yes
-
Indoor unit included:
-
No
-
Outdoor unit included:
-
Yes
-
Outdoor unit power type:
-
DC
-
Flash memory (transmitter):
-
32 MB
-
Internal memory (transmitter):
-
256 MB
-
Alarm input channels (transmitter):
-
4
