Type:
Characteristics of the device.
-
Basic access control reader
-
Power consumption (typical):
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
-
12 W
-
Operating relative humidity (H-H):
-
0 - 90
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-30 - 60
-
Height:
The measurement of the product from head to foot or from base to top.
-
177 mm
-
Input voltage:
The voltage (V) which is required to power the product.
-
12
-
Width:
The measurement or extent of something from side to side.
-
57.7 mm
-
Depth:
The distance from the front to the back of something.
-
34.6 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Silver
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
1
-
Buzzer:
-
Yes
-
Languages support:
The product has support (help) for languages.
-
Multi
-
Input current:
-
1
-
Fingerprint reader:
A scanner used to identify a person's fingerprint for security purposes. After a sample is taken, access to a computer or other system is granted if the fingerprint matches the stored sample. A PIN may also be used with the fingerprint sample.
-
No
-
Ethernet LAN data rates:
The different speed levels of the Ethernet LAN connection.
-
10, 100
-
Housing material:
What the casing of the product is made of.
-
Metal
-
PC connected:
The device is or can be connected to a PC.
-
Yes
-
RS-485 ports:
-
1
-
International Protection (IP) code:
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
-
IP65
-
Linux operating systems supported:
8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)
-
Yes
-
Built-in display:
A display which is part of the product, so you do not need to attach another display.
-
No
-
Alarm input/output:
-
Yes
-
Access code reader:
Device that is able to read an access code, and therefore determine whether the person with the card should be given access to the physical place or computer system.
-
Yes
-
Access chip/card reader:
Device that is able to read an access chip/card (smart card), and therefore determine whether the person with the card should be given access to the physical place or computer system.
-
Yes
-
Access chip/card reader type:
-
Contactless
-
Authentication type:
Authentification means proving identity to gain access to sometheng. There are various types of authentification exist e.g. access card, password, biometric data.
-
Access chip/card
-
Contactless working distance:
-
40 mm
-
IK code:
-
IK08
-
Front camera:
Camera at the front of the product.
-
No
-
Cards capacity:
-
10000 cards
-
Alarm input channels:
-
2
-
Alarm output channels:
-
1
-
Wiegand interface:
-
Yes
-
Tamper protection:
-
Yes
-
Event capacity:
-
100000
-
Open Supervised Device Protocol (OSDP):
-
Yes
-
Exit button:
-
Yes
-
Lock control:
-
Yes
-
Tamper:
-
Yes
-
Door contact input:
-
1
