Access Point HPE Aruba AP-535

Name: Access Point HPE Aruba AP-535 JZ336AR
Brand: HP Enterprise
SKU: 10696221
Price: 312.99 EUR
Availability: InStock

Shop for gifts early

Save time and money with our discounts!

Access Point HPE Aruba AP-535 2.4 GHz 5 GHz Wi-Fi 6

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Short description

The HPE Aruba AP-535 is a high-performance access point supporting dual-band Wi-Fi 6 with a maximum data transfer rate of 3550 Mbit/s. It features advanced security protocols including WMM, WPA, and WPA2, ensuring secure connectivity. With Ethernet LAN data rates of 100, 1000, 2500, and 5000 Mbit/s, and Power over Ethernet (PoE) support, it is ideal for modern networking needs. The sleek white design and a maximum power consumption of 23.3 W make it a perfect fit for any environment.

Available for order: 10 pcs.

Warranty: 2 Years

SKU: 10696221

Manufacturer: HP Enterprise

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

06.07.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

06.07.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

09.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 1.82 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend LV / DPD Paku skapis / Omniva LV / Venipak Pickup LV / Venipak Locker LV / Latvijas Pasts nodaļa

09.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

pay in 3 equal parts

today

0 €

afterward

3 mth. х 104.33 €

overpayment

0 €

All payment Methods Hide details

All payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay, Installment

36 months installment: from 8.69 euros per month

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The HPE Aruba AP-535 is a dual-band Wi‑Fi 6 access point designed for high-density environments, supporting simultaneous 2.4 GHz and 5 GHz operation with a maximum aggregate data rate of 3550 Mbit/s. It integrates Aruba 530 Series capabilities such as AI-powered RF optimization, WPA3-certified security, and Green AP power-saving mode to provide reliable connectivity for mobile and IoT devices. The AP supports multi-gig Ethernet (100/1000/2.5G/5G) and PoE options for flexible deployment.

Advantages

The AP-535 delivers up to four times the overall network performance versus 802.11ac APs by leveraging 802.11ax multi-user features and Aruba ClientMatch, which intelligently steers compatible clients to the best AP. AI/ML-driven Green AP mode can reduce energy usage by up to 70%. Intelligent Power Monitoring (IPM) enables operation even when connected switches provide limited PoE power. Integrated support for Bluetooth and Zigbee extends the device’s use for IoT and location services.

Suitable for

High-density office and campus deployments
Retail environments with many client devices
Hospitals and healthcare facilities requiring reliable wireless
IoT deployments using Bluetooth and Zigbee
Locations needing multi-gig Ethernet and PoE flexibility

Key specifications

Wireless standard: IEEE 802.11ax (Wi‑Fi 6), backward compatible with 802.11a/b/g/n/ac
Maximum data rate: 3550 Mbit/s (aggregate)
Bands: 2.4 GHz and 5 GHz (dual-band)
Ethernet LAN: 2 × RJ-45 ports; speeds 100 / 1000 / 2500 / 5000 Mbit/s
Antennas: 4 internal antennas
Security: WPA, WPA2, WPA3 support; WMM
Power: PoE support; maximum power consumption 23.3 W
Weight: 1.27 kg
Colour: White
Manufacturer part number (MPN): JZ336AR

How to use

Mount the AP-535 in the desired indoor location and connect it to the network via an Ethernet cable to a PoE-capable switch or injector supporting the listed IEEE 802.3 standards. Configure the device using Aruba management tools or a supported network controller, set SSID, security (WPA3 recommended where supported), and enable Aruba features such as ClientMatch and AI RF optimization. For IoT use cases, enable and configure Bluetooth and Zigbee support as required by your applications.

Usage recommendations

Place access points to provide overlapping coverage without creating excessive co‑channel interference; use Aruba’s AI RF tools to optimize placement and channel planning. For best performance, enable WPA3 where client devices support it, and use multi-gig switches when aggregating high traffic. Enable Green AP mode to reduce power consumption in low-traffic periods.

Specifications

Ethernet LAN (RJ-45) ports:: 2
Antennas quantity:: 4
Weight:: 1.27 kg
Maximum data transfer rate:: 3550 Mbit/s
Networking standards:: IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3z, IEEE 802.3at, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af
Product colour:: White

All features

Antenna

Antenna type:: Internal
Antenna gain level (max):: 5.4 dBi
Antennas quantity:: 4
Antenna features:: Integrated antenna
Antenna direction type:: Omni-directional

Operational conditions

Operating relative humidity (H-H):: 5 - 93
Storage temperature (T-T):: -40 - 70
Operating temperature (T-T):: 0 - 50
Storage relative humidity (H-H):: 5 - 93

Logistics data

Harmonized System (HS) code:: 85176990

Features

Maximum data transfer rate:: 3550 Mbit/s
Modulation:: 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK
Spread spectrum method:: DSSS, OFDM
Networking standards:: IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3z, IEEE 802.3at, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af
Ethernet LAN data rates:: 100, 1000, 2500, 5000
Auto MDI/MDI-X:: Yes
2.4 GHz:: Yes
5 GHz:: Yes
MIMO:: Yes
Maximum data transfer rate (2.4 GHz):: 1148 Mbit/s
Maximum data transfer rate (5 GHz):: 2402 Mbit/s

Ports & interfaces

USB connector type:: USB Type-A
USB 2.0 ports quantity:: 1
Ethernet LAN (RJ-45) ports:: 2

Power

Power over Ethernet (PoE):: Yes
Power consumption (max):: 23.3 W

Weight & dimensions

Weight:: 1.27 kg
Height:: 57 mm
Width:: 240 mm
Depth:: 240 mm

Design

Cable lock slot:: Yes
Product colour:: White
Placement:: Ceiling, Wall
Cable lock slot type:: Kensington

Security

Security algorithms:: WPA2, WMM, WPA
