Wired Router HUAWEI eKit AR300 Series AR303 Gigabit Ethernet IEEE 802.3

Ethernet interface type:

Gigabit Ethernet

Forwarding rate:

1 Mpps

Internal storage capacity:

1 GB

Power consumption (max):

12 W

Storage media:

Flash

Number of console ports:

1

SFP WAN:

No

WAN ports quantity:

1

WAN connection

SIM card slot:

No

3G/4G USB modem compatibility:

No

DSL WAN:

No

Ethernet WAN:

Yes

Ports & interfaces

Ethernet LAN data rates:

1000, 100, 10

Ethernet LAN (RJ-45) ports:

4

DC-in jack:

Yes

Network

Networking standards:

IEEE 802.3, IEEE 802.1p, IEEE 802.1Q

Cabling technology:

10/100/1000Base-T(X)

Port forwarding:

Yes

VPN support:

IPsec VPN, GRE VPN, DSVPN, L2TP VPN, L2TPv3VPN

Static route:

Yes

Policy-based routing:

Yes

Security

Security algorithms:

SNMP, IPSec

Firewall:

Yes

URL filtering:

Yes

Protocols

Routing protocols:

BGP4+, BGP, RIPng, RIP, OSPFv3, OSPF, IS-IS

Design

LED indicators:

Y

Product colour:

White

Rack capacity:

1U

Management features

Reset button:

Yes

Power

Power consumption (typical): Power consumption in switched-on state expressed in W.

9 W

Power source type:

AC

AC input frequency:

50/60

AC input voltage:

110 - 220

Weight & dimensions

Weight:

0.58 kg

Height:

38 mm

Width:

240 mm

Depth:

161.5 mm

Operational conditions

Operating altitude:

0 - 5000

Operating relative humidity (H-H):

5 - 95

Storage temperature (T-T):

-40 - 70

Operating temperature (T-T):

0 - 40

Certificates

Compliance certificates:

WEEE, RoHS, REACH, Electromagnetic Compatibility (EMC)

Other features

Rack mounting:

Yes

Number of users:

200 user(s)

Input current:

0.8

USB version:

2.0

USB ports quantity:

1

Packaging data

Package weight:

1180 g

Package depth:

297 mm

Package height:

90 mm

Package width:

370 mm

Features

Flash memory:

1000 MB
