Dimensions (WxDxH):
Dimensions of the product (Width x Depth x Height).
-
70 x 170 x 80
-
Wi-Fi standards:
The type of wireless local area network (LAN). It can be ad-hoc, where units in a network communicate peer-to-peer, or Infrastructure, where units communicate with each other via an access point A LAN interconnects computers in a small area e.g. home, school or office.
-
802.11b, 802.11g, Wi-Fi 4 (802.11n)
-
Security algorithms:
Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.
-
WPA, WPA2
-
Supported network protocols:
Network protocols tested as compatible with this product e.g. FTP,HTML, POP.
-
DHCP/IP/TCP/UDP
-
Operating relative humidity (H-H):
-
20 - 85
-
Compatible memory cards:
Types of memory cards which can be used with this product.
-
MicroSD (TransFlash)
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-30 - 65
-
Form factor:
The shape or design of the product.
-
Bullet
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
-30 - 50
-
Ethernet LAN:
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
-
No
-
Storage relative humidity (H-H):
-
0 - 90
-
Antenna type:
Type of antenna, also known an aerial, e.g. external, internal.
-
External
-
Sensor type:
A sensor is a convertor than measures a physical quality (light, temperature etc.) and displays this electronically on a device.
-
CMOS
-
Optical sensor size:
Optical sensors are electronic detectors that convert light, or a change in light, into an electronic signal. They are used in many industrial and consumer applications e.g. lamps that turn on automatically in response to darkness. Optical sensors come in many sizes.
-
25.4 / 2.7
-
Connectivity technology:
The technology that enables connectivity of the device, e.g. wired or wireless.
-
Wired & Wireless
-
Maximum resolution:
The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
-
1920 x 1080
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
-
LED type:
-
IR
-
Maximum operating distance:
The maximum distance from which you can operate the device.
-
45 m
-
Video compression formats:
-
H.264
-
Length:
The measurement or extent of something from end to end.
-
165 mm
-
Wi-Fi data rate (max):
-
300
-
Wi-Fi:
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
-
Yes
-
Card reader integrated:
A card reader is a device that enables reading and, in some cases, writing data to and from a memory card.
-
Yes
-
Placement supported:
Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.
-
Outdoor
-
Frame rate:
-
25 fps
-
Housing material:
What the casing of the product is made of.
-
Glass, Plastic, Metal
-
Night vision:
Night vision is technology which allows you to see in low light conditions.
-
Yes
-
Number of illumination LEDs:
-
4
-
Mounting type:
Type of mounting e.g. wall mounting.
-
Ceiling/Wall
-
Video motion detection:
-
Yes
-
Antennas quantity:
-
1
-
DC output voltage:
-
12
-
DC output current:
-
1 A
-
Maximum memory card size:
The maximum size of memory card that can be used with this device.
-
128 GB
-
Lens diameter:
The size of the lens, measured by drawing a straight line from one side to the other, going through the centre of the lens.
-
3.6 mm
-
Built-in HDD:
The product has a hard drive built into it.
-
No
-
Night vision distance:
-
5
-
Number of cameras:
The quantity of cameras that product can support.
-
1
-
Screws included:
-
Yes
-
Number of lenses:
The number of lenses installed in the device.
-
1
-
Number of sensors:
-
1
-
Lens viewing angle, horizontal:
-
75
-
Lens viewing angle, vertical:
-
75
