Cable gender changer InLine 92504M — audio/video adapter, model 92504M

The InLine 6.35 mm jack plug (TS, mono) on a 2‑pole screw terminal block provides a solder‑free solution for wiring analog audio signals, control lines, or test setups. The adapter accepts wire sizes 18–26 AWG and uses a clearly labeled terminal assignment (+ = signal, – = ground). A robust housing with an EVA insulation layer on the underside protects when mounted on conductive surfaces, and the compact form factor allows space‑saving integration in audio racks, test systems, or embedded projects.

Advantages

Quick wiring via screw terminals saves installation time and supports tool‑assisted connection with a flat‑head screwdriver up to 2.5 mm. The 6.35 mm TS jack plug provides a reliable mono audio connection with clearly assigned signal and ground terminals. Adjacent terminals in a 5.0 mm pitch enable compact installation, and the adapter is rated for stable signal transmission with insulation resistance ≥ 10 MΩ (300 V DC) and a rated current of 1.0 A per pin.

Suitable for

• Analog audio connections in studios and PA systems
• Control lines and signal routing in test setups
• Development labs and measurement systems
• Compact audio racks and embedded audio projects

Key specifications

• Jack connection: 6.35 mm TS (2‑pin, mono)
• Terminals / assignment: 2 terminals / + (signal), – (ground)
• Connection technology: Screw terminal with pressure plate, 5.0 mm pitch
• Connection range: 18–26 AWG
• Actuation: Flat‑blade screwdriver ≤ 2.5 mm
• Rated current: 1.0 A per pin
• Max. operating voltage: 100 V between two signals
• Insulation resistance: ≥ 10 MΩ @ 300 V DC
• Max. conductor resistance: 5 Ω
• Operating temperature: –10 °C to +70 °C
• Insulation layer: EVA insulation on underside

How to use

Strip the conductor to an appropriate length, insert the wire into the matching screw terminal (observe + = signal, – = ground) and tighten the screw using a flat‑head screwdriver (maximum blade width 2.5 mm) until the conductor is clamped securely. Plug the 6.35 mm TS jack into the corresponding mono socket. Mount the adapter in the desired location, ensuring the EVA insulation layer faces any conductive surface.

Usage recommendations

For best performance, use copper conductors within the specified 18–26 AWG range, avoid over‑torquing the terminal screws, and keep the operating temperature within –10 °C to +70 °C. Do not exceed the rated current of 1.0 A per pin and ensure proper polarity when connecting signal and ground.
