Measuring Set INSIZE MMWC-S 2‑piece depth micrometer 50–600 mm

INSIZE MMWC-S 2-piece depth micrometer 50–600 mm is a precision measuring set designed to provide consistent depth and step measurements across a wide working range. The set combines two micrometer heads calibrated to cover the 50–600 mm span, enabling accurate measurement of recesses, slots and stepped features in production and inspection environments. The measuring heads are intended for workshop and quality-control use where repeatable results and clear readouts are required.

Advantages

The 2-piece configuration offers extended range without sacrificing accuracy, allowing users to measure deeper features without changing tool types. Precision-ground contact faces and stable spindle mechanics provide repeatable readings. The modular design simplifies handling and storage, and compatibility with standard anvils and accessories ensures adaptability to different measurement tasks. The set is suitable for environments where robust, stable depth measurement is needed.

Suitable for

• Depth and step measurements on machined parts
• Inspection and quality-control of recesses and slots
• Metalworking and toolroom measurement tasks
• Workshop setups requiring extended-range depth measurement

Key specifications

• Measuring range: 50–600 mm (two-piece set)
• Measuring principle: mechanical micrometer heads for depth measurement
• Contact face: precision-ground contact surfaces for repeatability
• Resolution: typical micrometer resolution suitable for workshop metrology (refer to manufacturer data for exact step size)
• Construction: rigid frame and stable spindle assembly for consistent readings
• Intended use environment: workshop, machining and inspection stations

How to use

Set up the appropriate micrometer head and frame section to span the target depth. Place the frame on the reference surface so the contact face is aligned with the feature to be measured. Rotate the spindle until the contact face engages the bottom of the recess or step, and read the depth value according to the micrometer scale. When measuring depths beyond the single-head range, assemble the second piece according to the set instructions to extend the measuring span. Handle the measuring heads carefully and avoid lateral forces that can affect accuracy.

Usage recommendations

Store the set in a protective case when not in use, keep contact faces clean and free of debris, and periodically check calibration against a reference standard. Use gentle and consistent measuring force and avoid using the instrument in environments with excessive vibration or temperature fluctuations to maintain measurement accuracy.
