Measuring tool INSIZE 6562-4 edge finder (Insize Czujnik krawędzi)

Edge finder INSIZE model 6562-4 is a precision measuring tool designed to locate and mark the edge of workpieces. It is intended for use during machine setup and inspection tasks on milling machines, drill presses and inspection benches. The device enables quick detection of material edges to establish reference zero points, helping to reduce setup time and improve repeatability in machining operations. Its compact form factor makes it practical for workshop use and for transferring accurate X/Y references from part edges.

Advantages

The INSIZE 6562-4 edge finder provides accurate edge detection with a simple mechanical contact method that requires no power source. Its compact construction offers ease of handling and positioning in restrictive setups. The measured contact point gives a clear reference for establishing machine coordinates and aligns easily with standard tool holders. The tool is suitable for repeated use in production and maintenance environments where consistent edge detection is required.

Suitable for

• Locating and marking the edge of workpieces on milling machines
• Setup operations on drill presses and vertical machining centers
• Inspection benches where quick reference point determination is needed
• Workshop and maintenance tasks that require accurate X/Y referencing

Key specifications

• Function: mechanical edge detection for establishing workpiece zero/reference points
• Design: compact hand-held style suitable for mounting in standard tool holders
• Operation: contact-based detection requiring physical engagement with the workpiece edge
• Application environment: milling machines, drill presses, inspection benches and general workshop use

How to use

Mount the edge finder in the machine spindle or tool holder and slowly advance it toward the workpiece until contact is made and the contact point is registered. Rotate the spindle or gently move the tool to ensure accurate seating against the edge, then note the machine coordinate readout to establish the workpiece zero or reference position. Retract the edge finder and replace with the working cutting tool after confirming the reference. Use steady feed and avoid excessive force during contact to maintain tool accuracy and prevent damage.

Usage recommendations

Keep the contact tip and tool holder clean and free of chips or coolant to ensure repeatable results. Verify alignment on a known reference before critical setups and handle the tool carefully to avoid impacts that could alter accuracy.
