Type:
Characteristics of the device.
-
Server
-
Rack mounting:
The type of mounting that can position devices in a shelving system (rack).
-
Yes
-
Form factor:
The shape or design of the product.
-
Rack
-
Material:
The material from which a thing is or can be made e.g. wood, plastic.
-
Steel
-
Height:
The measurement of the product from head to foot or from base to top.
-
45 mm
-
Width:
The measurement or extent of something from side to side.
-
485 mm
-
Depth:
The distance from the front to the back of something.
-
285 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Audio input:
The type of audio input that the device requires, and the connection needed.
-
No
-
Audio output:
The type of audio output that the device produces, and the connector(s).
-
No
-
USB 2.0 ports quantity:
Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.
-
2
-
Rack capacity:
The spase that device fill in rack.
-
1U
-
Supported motherboard form factors:
Design of the supported motherboards.
-
Mini-ITX
-
Number of 5.25" bays:
A drive bay is a standard-area for adding hardware to a computer. Most drive bays are fixed to the inside of a case, but some can be removed. A 5.25" drive bay, also known as full-height bays, were found in old PCs in the early to mid-1980s. They were 3¼″ high by 5¾″ wide, and up to 8″ deep (83 × 146 × 200 mm), used mainly for hard disks and floppy disk drives.
-
0
-
Number of 3.5" bays:
A drive bay is a standard-area for adding hardware to a computer. Most drive bays are fixed to the inside of a case, but some can be removed. A 3.5" drive bay is for floppy disks.
-
1
-
Power supply included:
There is a power supply with this product.
-
No
-
Side window:
A side window is a transparent side (or part of side) in a housing which enables you to see the internal space of the device.
-
No
-
Number of internal 3.5" bays:
-
1
-
Number of 2.5" bays:
-
2
-
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
-
0
-
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:
Number of USB 3.1 (3.1 Gen 2) ports with Type-C connector. USB 3.1 (3.1 Gen 2) is USB interface version which supports transfer rate up to 10 Gbit/s (SuperSpeed+). USB Type-C connector has symmetrical design architecture and compatible with Thunderbolt 3 interface.
-
0
-
Harmonized System (HS) code:
-
84733080
