USB-C to 4K HDMI Adapter j5create JCA153G-N Grey Aluminium

Mac compatibility: Product can be used with Apple Mac software and/or hardware.

Yes

Output voltage:

5

USB connector type: The type of USB connector/port that this product has.

USB Type-C

Cables included:

USB Type-C

HDMI ports quantity: The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.

1

Integrated USB cable:

Yes

Quick installation guide:

Yes

Current:

0.14 A

Linux operating systems supported: 8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)

Yes

Other operating systems supported:

Android

USB cable length:

0.145 m

USB version: Universal Serial Bus (USB) is an industry standard developed in the mid-1990s that defines the interface used for connection, communication and power supply between computers and electronic devices. Every new version - for example 1.1, 2.0, 3.0 - is much faster than the previous one.

2.0/3.2 Gen 1 (3.1 Gen 1)

Power consumption (max): The maximum amount of power used by the device.

0.7 W

Number of displays supported: The number of displays that can be used with this product.

1

Packaging content:

1 x JCA153G USB Type-C to 4K HDMI Adapter, 1 x Quick Installation Guide

Maximum resolution (HDMI):

3840 x 2160

DVI output:

No

Refresh rate at maximum resolution:

60 Hz

DisplayPort output: The device features a DisplayPort (DP) output to accomodate a standardized digital display interface used to connect a video source to a display device such as a computer monitor, and it can also carry audio, USB, and other forms of data.

No

HDMI output: The device features an HDMI output.

Yes

Resolution at refresh rate:

4k @ 30Hz 4k @ 60Hz

USB connector gender:

Male

Logistics data

Warranty period:

2 year(s)

Products per master (outer) case:

20 pc(s)

Master (outer) case gross weight:

1790 g

Master (outer) case height:

180 mm

Master (outer) case length:

321 mm

Master (outer) case width:

225 mm

Country of origin: Country where the device is made. Aka Country of manufacture (COM).

Taiwan

Shipping (inner) case width:

105 mm

Shipping (inner) case length:

150 mm

Shipping (inner) case height:

160 mm

Products per shipping (inner) case:

5 pc(s)

Master (outer) case GTIN (EAN/UPC):

24712795081927

Export Control Classification Number (ECCN):

EAR99

Technical details

Housing material: What the casing of the product is made of.

Aluminium

Other features

Height: The measurement of the product from head to foot or from base to top.

14 mm

Width: The measurement or extent of something from side to side.

23 mm

Depth: The distance from the front to the back of something.

68 mm

Packaging content

Batteries included:

No

Quantity per pack:

1 pc(s)

Packaging data

Package weight: Weight of the packaged product.

52 g

Package height: The distance from the top to the bottom of the packaging.

25 mm

Package depth: The distance from the front to the back of the packaging.

95 mm

Package width: The distance from one side of the packaging to the other.

145 mm

Weight & dimensions

Weight: Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.

0.025 kg

Operational conditions

Storage temperature (T-T): The minimum and maximum temperatures at which the product can be safely stored.

-10 - 71

Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.

0 - 40

Features

Mac operating systems supported: Mac operating systems e.g. OS X can be used with the device.

Yes

Windows operating systems supported: Windows vesions wich can be used with the device.

Yes

Cable type: Type of cable e.g. electicity cable, optical cable.

USB-C

HDMI version:

2.0

Product colour: The colour e.g. red, blue, green, black, white.

White, Grey

Maximum resolution: The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.

3840 x 2160
