Receiver sensitivity:
-
5 GHz:
-80 dBm @ 54 MBit/s, IEEE 802.11an/ac: -75 dBm @ (MCS7, 20/40MHz), -71 dBm @ (MCS9, 20/40 MHz), -68 dBm (MCS9, 80 MHz)
2.4 GHz:
-80 dBm @ 54 MBit/s, IEEE 802.11n: -77 dBm @ (MCS7, 20 MHz), -75 dBm @ (MCS7, 40 MHz)
-
Maximum outdoor range:
The maximum distance to which the signals are transmitted, when the device is used outdoors.
-
150 m
-
Maximum indoor range:
The maximum distance to which the signals are transmitted, when the device is used indoors.
-
30 m
-
Quality of Service (QoS) support:
-
Yes
-
Operating modes:
-
Access Point (AP),Bridge,Client
-
VLAN support:
A Virtual Local Area Network (VLAN) consists of a group of computers and switches that can be physically distributed over different networks and buildings, but form one LAN on a logical level.
-
Yes
-
Wi-Fi Multimedia (WMM)/(WME):
-
Yes
-
Modulation:
Modulation is the process of varying one or more properties of a periodic waveform, called the carrier signal (High Frequency Signal), with a modulating signal which typically contains information to be transmitted. The aim of digital modulation is to transfer a digital bit stream over an analog bandpass channel, for example over the public switched telephone network (where a bandpass filter limits the frequency range to between 300 and 3400 Hz), or over a limited radio frequency band. The aim of analog modulation is to transfer an analog baseband (or lowpass) signal, for example an audio signal or TV signal, over an analog bandpass channel at a different frequency, for example over a limited radio frequency band or a cable TV network channel.
-
256-QAM
-
Automatic channel selection:
-
Yes
-
Networking standards:
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
-
IEEE 802.11g, IEEE 802.3at, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11h, IEEE 802.11i, IEEE 802.11u, IEEE 802.3u, IEEE 802.3af, IEEE 802.3ab, IEEE 802.3, IEEE 802.1x, IEEE 802.11w, IEEE 802.11n
-
Frequency band:
A small section of the spectrum of radio communication frequencies, in which channels are usually used or set aside for the same purpose e.g.for a channel on FM radio; for mobile networks to communicate with mobile phones.
-
2.4 - 2.4835, 5.15 - 5.7
-
Throughput data rate:
-
250 Mbit/s
-
Ethernet LAN data rates:
The different speed levels of the Ethernet LAN connection.
-
1000, 100, 10
-
Maximum data transfer rate (5 GHz):
-
867 Mbit/s
-
Maximum data transfer rate (2.4 GHz):
-
300 Mbit/s
-
Maximum data transfer rate:
The maximum speed with which data can be transmitted from one device to another.
-
867 Mbit/s
-
5 GHz:
-
Yes
-
6 GHz:
-
No
-
2.4 GHz:
-
Yes
