Wireless Access Point Lancom Systems LANCOM LX-6200E — Dual‑Band 2.4/5 GHz, PoE, Gigabit Ethernet, WPA3

The LANCOM LX-6200E is a compact dual-band wireless access point that provides Wi‑Fi 6 performance for small to medium user densities. It operates concurrently on the 2.4 GHz and 5 GHz bands, supports modern security with WPA3, and offers Gigabit Ethernet connectivity with Power over Ethernet (PoE) power supply. With integrated Bluetooth Low Energy (BLE) and a USB 2.0 interface, the LX-6200E also supports the integration of IoT devices and peripheral systems while remaining suitable for business and enterprise WLAN deployments.

Advantages

The device delivers aggregated dual‑band throughput of up to 1,775 Mbps, using IEEE 802.11ax to provide up to 1,200 Mbps at 5 GHz and up to 575 Mbps at 2.4 GHz. 2x2 MU‑MIMO handles multiple clients simultaneously in both downlink and uplink directions, which improves spectral efficiency and reduces latency in busy networks. Professional IoT support through BLE 5.1 and a USB 2.0 port enables connection of sensors, beacons or ePaper solutions. Management is flexible: the access point can be operated via the LANCOM Management Cloud, a LANCOM WLAN controller, or in stand‑alone mode. Security is provided by WPA3 for both personal and enterprise scenarios.

Suitable for

• Small and medium offices
• Hotels and guest accommodations
• Medical practices and clinics (non‑life‑supporting environments)
• Branch offices and retail locations
• IoT deployments such as digital signage, asset tracking, or electronic shelf labels

Key specifications

• Wireless standard: IEEE 802.11ax (Wi‑Fi 6) with backward compatibility to previous Wi‑Fi standards
• Dual concurrent operation on 2.4 GHz and 5 GHz
• Maximum aggregated data rate: up to 1,775 Mbps (5 GHz up to 1,200 Mbps; 2.4 GHz up to 575 Mbps)
• MIMO: 2x2 MU‑MIMO for downlink and uplink
• Bluetooth Low Energy: version 5.1
• Interfaces: Gigabit Ethernet ports with Power over Ethernet (PoE); USB 2.0 port
• Security: WPA3 support
• Power consumption: typical maximum 17.3 W
• Housing: compact internal/ceiling mounting style, white
• Standards support: IEEE 802.11a/b/g/n/ac/ax and IEEE 802.3az energy‑efficient Ethernet

How to use

Mount the LANCOM LX-6200E in the chosen coverage area and connect it to a network switch or PoE injector to provide power and network connectivity. Configure the access point either as a stand‑alone device, through a LANCOM WLAN controller, or via the LANCOM Management Cloud depending on your orchestration needs. Use the web interface or management platform to set SSIDs, security (WPA3), radio settings, and any IoT integration parameters for BLE or USB devices. Verify coverage and channel assignments to minimize interference and optimize client performance.

Usage recommendations

Place the access point centrally relative to the intended client area and avoid physical obstructions for best radio performance. Enable WPA3 where client devices support it, and use the management cloud or controller for centralized firmware updates and policy enforcement. For IoT scenarios, keep BLE and USB peripheral firmware up to date and separate guest traffic from operational IoT traffic using VLANs or SSID segmentation.
