Access Point LANCOM LX-6500

Name: Access Point LANCOM LX-6500 Bulk 61863
Brand: Lancom
SKU: 6522037
Price: 9958.99 EUR
Availability: InStock

Shop for gifts early

Save time and money with our discounts!

Access Point LANCOM LX-6500 Bulk 10 2.4 GHz 5 GHz 6 GHz

Keep track of price changes You keep track of price changes

Scan qr code below, or type in manually: {{secretKey}}

Forgot password? Registration

Short description

The LANCOM LX-6500 is a versatile access point supporting 2.4 GHz, 5 GHz, and 6 GHz bands with a maximum data transfer rate of 54 Mbit/s. It features robust security with EAP-FAST, EAP-TLS, and EAP-TTLS algorithms. With Ethernet LAN data rates of 10, 100, 1000, and 2500 Mbit/s, it ensures high-speed connectivity. The device supports Power over Ethernet (PoE) and has a maximum power consumption of 33 W. Its sleek white design fits seamlessly into any environment.

Available at price 9,958.99 €: 1 pcs.

Total available for order: 2 pcs.

Warranty: 2 Years

SKU: 6522037

Manufacturer: Lancom

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

14.10.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

14.10.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

19.10.2026 {{selectedOffer.courierDeliveryString}}

From 15.04 € (Weight: 19.35 kg)

More about delivery methods

Payment Methods:

Bank transfer, Bank cards on-line, Apple Pay, Google Pay, Leasing for legal entities

Find out more Hide details

Leasing for legal entities: from 346.57 euros per month

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The LANCOM LX-6500 is a tri-band Wi‑Fi 6E access point supporting 2.4 GHz, 5 GHz and the new 6 GHz band to provide high-throughput, low-interference wireless connectivity. As a business-grade access point it aggregates the available WLAN spectrum to deliver combined data rates and improved capacity for modern, bandwidth-demanding applications while offering flexible management and power options.

Advantages

The LANCOM LX-6500 uses Wi‑Fi 6E to open an interference-reduced 6 GHz band and increases the total radio spectrum for higher aggregated throughput and lower latency. It supports 4x4 MU‑MIMO in both downlink and uplink, OFDMA for efficient multi-client transmission, and Target Wake Time (TWT) to reduce client power consumption. Management can be done via LANCOM Management Cloud, WEBconfig, or a WLAN controller. The device supports PoE (IEEE 802.3bt) or an optional power supply and includes Bluetooth Low Energy (5.1) and USB 3.0 for IoT integration.

Suitable for

High-density Wi‑Fi networks in offices, education and public venues
Bandwidth-intensive applications such as 4K/8K streaming, AR/VR and cloud collaboration
IoT deployments requiring BLE or USB peripherals (asset tracking, ePaper, electronic shelf labels)
Environments needing centralized or cloud-based network management

Key specifications

Wireless bands: 2.4 GHz, 5 GHz, 6 GHz (Wi‑Fi 6E / IEEE 802.11ax)
Spatial streams: 4x4 (MU‑MIMO downlink and uplink)
Peak aggregated WLAN throughput: up to 8.4 Gbps (combined across bands)
Channel widths supported: 20 / 40 / 80 / 160 MHz
OFDMA, TWT, BLE 5.1, USB 3.0
Ethernet ports (RJ-45): 2
Ethernet speeds supported: 10 / 100 / 1000 / 2500 Mbit/s
Power: PoE IEEE 802.3bt (4PPoE recommended) or optional PSU; max. power consumption 33 W
Colour: White
MPN: 61863, EAN: 4044144618635

How to use

Install the LX-6500 at a central, elevated location to maximize coverage and minimize obstructions. Connect to a PoE-capable Ethernet port (IEEE 802.3bt recommended) or attach the optional power supply. Configure the device using the LANCOM Management Cloud for centralized orchestration, WEBconfig for local web-based setup, or through an existing WLAN controller. Allocate SSIDs and security settings (EAP methods supported) and map clients to preferred bands to balance load across 2.4 GHz, 5 GHz and 6 GHz.

Usage recommendations

For best performance in high-density environments, use a PoE++ (4PPoE) switch to ensure full power delivery, enable band steering to place modern clients into the 6 GHz band, and monitor client distribution via cloud or controller tools to optimize channel planning and avoid local interference.

Specifications

Antenna type: Type of antenna, also known an aerial, e.g. external, internal.: Internal
Power over Ethernet (PoE): The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.: Yes
USB 2.0 ports quantity: Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.: 1
Ethernet LAN (RJ-45) ports: Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.: 2
Maximum data transfer rate: The maximum speed with which data can be transmitted from one device to another.: 54 Mbit/s
6 GHz:: Yes
5 GHz:: Yes
2.4 GHz:: Yes
Product colour: The colour e.g. red, blue, green, black, white.: White
Security algorithms: Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.: EAP-TTLS, EAP-TLS, EAP-FAST

All features

Logistics data

Country of origin: Country where the device is made. Aka Country of manufacture (COM).: China, Malaysia
Customs product code (TARIC):: 85176200

Operational conditions

Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.: 0 - 40
Operating relative humidity (H-H):: 0 - 90

Packaging content

Cables included:: LAN (RJ-45)
Quantity per pack:: 10 pc(s)

Packaging data

Package weight: Weight of the packaged product.: 19350 g

Weight & dimensions

Height: The measurement of the product from head to foot or from base to top.: 42 mm
Depth: The distance from the front to the back of something.: 230 mm
Width: The measurement or extent of something from side to side.: 230 mm

Antenna

Antenna type: Type of antenna, also known an aerial, e.g. external, internal.: Internal

Design

LED indicators:: Y
Housing material: What the casing of the product is made of.: Aluminium, Synthetics
Product colour: The colour e.g. red, blue, green, black, white.: White

Power

Power consumption (max): The maximum amount of power used by the device.: 33 W
DC voltage range:: 12
AC input voltage: The voltage of the AC electricity that is inputted into the product.: 230
Power over Ethernet (PoE): The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.: Yes

Ports & interfaces

DC-in jack: The socket/plug where the DC electricity supply connects to the device.: Yes
USB 2.0 ports quantity: Number of USB 2.0 ports (connecting interfaces) in the device. USB 2.0 was released in April 2000 (now called "Hi-Speed"), adding higher maximum signaling rate of 480 Mbit/s (effective throughput up to 35 MB/s or 280 Mbit/s), USB 2.0 ports are usually black.: 1
Ethernet LAN (RJ-45) ports: Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.: 2

Management features

Syslog:: Yes
Web-based management: Using a website/web application to manage something.: Yes

Protocols

Supported network protocols: Network protocols tested as compatible with this product e.g. FTP,HTML, POP.: IPv4, IPv6, LLDP, Proxy ARP, LACP, L2TPv3

Security

IGMP snooping:: Yes
Number of SSID supported:: 32
Service Set Identifier (SSID) features:: Multiple SSIDs
MAC address filtering: Security access control method whereby the 48-bit address assigned to each network card is used to determine access to the network. MAC addresses are uniquely assigned to each card, so using MAC filtering on a network permits and denies network access to specific devices through the use of blacklists and whitelists.: Yes
Security algorithms: Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.: EAP-TTLS, EAP-TLS, EAP-FAST

Features

Quality of Service (QoS) support:: Yes
Dynamic Frequency Selection (DFS):: Yes
Band steering:: Yes
Rate limiting:: Yes
Number of VLAN IDs:: 4096
VLAN support: A Virtual Local Area Network (VLAN) consists of a group of computers and switches that can be physically distributed over different networks and buildings, but form one LAN on a logical level.: Yes
MIMO type:: Multi User MIMO
MIMO:: Yes
Automatic channel selection:: Yes
Automatic channel scanning:: Yes
Number of users: The number of people that use or can use this product.: 512 user(s)
Ethernet LAN data rates: The different speed levels of the Ethernet LAN connection.: 2500, 10, 100, 1000
Maximum data transfer rate (5 GHz):: 1733 Mbit/s
Maximum data transfer rate (6 GHz):: 54 Mbit/s
Maximum data transfer rate (2.4 GHz):: 600 Mbit/s
Maximum data transfer rate: The maximum speed with which data can be transmitted from one device to another.: 54 Mbit/s
5 GHz:: Yes
6 GHz:: Yes
2.4 GHz:: Yes

Hide Show all

Instructions

mmo_101378717_1732018541_9958_521495.pdf

Description

Instructions

mmo_101378717_1732018541_9958_521495.pdf

Machine translation. Load original

Show details Hide details

{{highlightedFeature.featureTitle}}:

{{getProductFeatureValueById(product, highlightedFeature.featureId)}}

Warehouse	Stock	Delivery to the store	Store Price
EU3	1	14.10.2026 Best delivery	9,958.99 € Best price
WH357	1	14.10.2026 Best delivery	11,163.49 €

9,958.99 €

Stock: 1

Delivery Date: 14.10.2026 Best delivery

Warehouse: EU3

11,163.49 €

Stock: 1

Delivery Date: 14.10.2026 Best delivery

Warehouse: WH357

Customer reviews

Show all reviews

Customer questions

FAQ

How much does the Access Point LANCOM LX-6500 cost, and is it available for purchase?

The price is 9,958.99 € (valid at the time of publication and already includes all taxes). The item is available for order — 2 pcs. are in stock, and you can place your purchase right now with delivery across Latvia and Europe or choose pickup at the Riga collection point. We offer favorable purchase terms, including the option to split the payment into convenient monthly installments. Availability and price are updated in real time, so we recommend placing your order in advance.

If I order this product today, when will I receive my order?

If you place your order today, delivery will be as fast and convenient as possible. You will be able to pick up your order on 14.10.2026 at the Riga pickup point or choose delivery across Latvia and Europe. We carefully inspect every purchase and pack it securely for safe transportation.

What payment options are available?

AiO.lv offers several payment methods: Bank transfer, Bank cards on-line, Apple Pay, Google Pay, Leasing for legal entities. All transactions are 100% secure and encrypted.

Can this product be purchased for a company (with VAT)?

Yes. AiO.lv works with legal entities in Latvia and across Europe. The product price already includes VAT. For certain product categories, as well as for companies from other EU countries with a valid VAT number, a 0% VAT rate may apply. We issue the invoice immediately after the order is placed, support electronic BIS invoices, and automatically generate all necessary accounting documents. You can complete the purchase for a company online — simply select the company profile and choose bank transfer as the payment method during checkout.

What is the warranty period?

All Lancom products come with an official 2 Years warranty. It covers all manufacturing defects and malfunctions that may occur during use. The warranty is valid at all authorized Lancom service centers and through AiO.lv

Can the product be returned after purchase?

Yes, you can return the product within 14 days of purchase if you bought it as a consumer (not a legal entity). Returns are possible without giving any reason — the main condition is that the product retains its original appearance and full set of accessories. We will make the process as simple and convenient as possible: just contact our customer support team, and we will help you arrange the return.

Where should I contact for warranty service?

For warranty-related questions you can contact the AiO.lv (SIA VSPRO) customer support team. We will assist with consultation, warranty claim processing, and coordination with certified service centers.

How can I tell if this product suits my needs?

When making a choice, we recommend paying attention to the key features: antenna type, power over ethernet (poe), usb 2.0 ports quantity, ethernet lan (rj-45) ports, maximum data transfer rate, 6 ghz, 5 ghz, 2.4 ghz, product colour, security algorithms, compatibility with your devices or usage conditions, material quality, functionality, and warranty terms. These characteristics will help you determine how well the model meets your needs.

Where can I download the instructions for Access Point LANCOM LX-6500?

You can download the instructions in PDF format from the “Instructions” section on the product description page. The file contains complete information about installation, setup, and usage.
