LED strip LEMLUX HM-S-120LED-W 5 m, 120 LED/m, 6500K

LEMLUX HM-S-120LED-W is a 5 m LED strip operating at 24 V DC with a density of 120 SMD 2835 LEDs per metre and a cold white colour temperature of 6500 K. The strip delivers approximately 1200 lm per metre with a 120° beam angle, mounted on a 6 mm PCB and protected to IP20. It is intended for general lighting, task illumination and interior accenting and includes a 5-year warranty. Note: the LED strip must be connected from one side and the connection point should be less than 1.5 m from the strip end.

Advantages

The strip provides high LED density for uniform light distribution and a high lumen output of about 1200 lm/m. Operating at 24 V DC and 10 W/m power consumption, it supports longer runs with reduced voltage drop compared with lower-voltage strips. The 6 mm PCB and 120° beam angle ensure stable mounting and broad light spread. A 5-year warranty covers manufacturing defects.

Suitable for

• General indoor lighting in homes and offices
• Under-cabinet and task lighting in kitchens or workspaces
• Accent and cove lighting to highlight architectural details
• Backlighting panels and displays

Key specifications

• Product code: HM-S-120LED-W
• Length: 5 m
• Operating voltage: 24 V DC
• Power consumption: 10 W/m
• LED type and density: SMD 2835, 120 LED/m
• Colour temperature: 6500 K (cold white)
• Luminous flux: ~1200 lm/m
• Beam angle: 120°
• CRI: >80
• PCB width: 6 mm
• Cut segment: 25 mm
• IP rating: IP20
• Warranty: 5 years

How to use

Measure and prepare a clean, dry mounting surface. Cut the strip only at designated 25 mm cut points. Connect the strip to a compatible 24 V DC power supply or controller, ensuring the connection is made from one side and within 1.5 m of the strip end to avoid voltage and brightness issues. Secure the strip onto the mounting surface with appropriate adhesive or mounting accessories and route wiring so it is protected and accessible for service.

Usage recommendations

For best performance, use a suitably sized 24 V DC power supply and consider supplying power from both ends or adding feed points for runs longer than recommended to minimise voltage drop. Avoid exposure to moisture or outdoor environments due to IP20 rating.
