LED strip LEMLUX NF-9W24V-RH5M 24Vdc 7.2W/m 5 m

LEMLUX NF-9W24V-RH5M is a 5 m flexible LED strip for 24 Vdc systems, providing continuous low-voltage illumination for accent, task or ambient lighting in residential and commercial interiors. The strip uses 2835 SMD LEDs with Epistar chips and is supplied on a 5 m roll suitable for mounting in aluminum channels or brackets. It is cuttable at 25 mm intervals and rated IP68 for protected installations with an expected lifetime of up to 50,000 hours and a 3-year warranty.

Advantages

The LED strip offers a compact 180° beam angle and a high LED density (120 LEDs per meter) for uniform light distribution. With a durable IP68 rating and an operating temperature range from −25°C to 60°C, the product is suitable for a variety of indoor and protected outdoor applications. Its Epistar chipset supports stable performance and long lifetime while the 5 m roll format simplifies long runs and installations.

Suitable for

• Accent lighting for coves, shelves and display cases
• Under-cabinet and task lighting in kitchens and workspaces
• Linear illumination in retail and hospitality environments
• Protected outdoor or damp locations when installed with appropriate profiles

Key specifications

• Voltage: 24 V DC
• Power: 9 W/m (product listing notes 7.2 W/m in summary — use compatible 24 V driver)
• LED type: 2835 SMD
• LED quantity: 120 LEDs/m
• Chip brand: Epistar
• Beam angle: 180°
• IP rating: IP68
• Operating temperature: −25°C to 60°C
• Dimensions (strip): 50,000*06*12 mm (manufacturer data)
• Cuttable length: 25 mm
• Roll length: 5 m (net weight 0.6 kg)
• Lifespan: 50,000 hours
• Warranty: 3 years

How to use

Install the LED strip on a clean, dry surface using the recommended installation brackets or an aluminum channel to ensure heat dissipation and secure mounting. Cut the strip only at marked 25 mm intervals and make electrical connections to a compatible 24 V DC driver. Observe correct polarity and use appropriate connectors or soldering techniques; seal connections when used in damp or wet locations to maintain IP68 protection.

Usage recommendations

For reliable performance, use a 24 V DC constant-voltage driver rated for the strip’s total length and power consumption, allow for ventilation or an aluminum profile for heat management, and avoid bending the strip sharply. When installed outdoors or in wet areas, ensure end caps and connection points are properly sealed to preserve the IP68 rating.
