ATC approved:
-
No
-
Nominal attenuation:
-
300kHz-825MHz <5dB 825MHz-2.475GHz <5dB 2.475GHz-4.125GHz <12dB 4.125GHz-5.1GHz <20dB
-
Cable type:
Type of cable e.g. electicity cable, optical cable.
-
Round cable
-
Colour depth:
-
8 bit
-
Colour sampling:
-
4:4:4
-
Bend radius (min):
-
22 mm
-
Shield material:
-
Aluminium
-
Cable jacket material:
-
Polyvinyl chloride (PVC)
-
Connector material:
-
Nickel
-
Contact material:
-
Phosphor bronze
-
Data transfer rate:
Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations.
-
18 Gbit/s
-
AWG wire size:
-
3/0
-
Connector housing material:
-
Polyvinyl chloride (PVC)
-
Cable material:
The material e.g. copper, steel from which the cable is made.
-
Copper-Clad Steel (CCS)
-
HDMI Ethernet channel:
-
Yes
-
Supported graphics resolutions:
The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
-
4096 x 2160
-
HDMI version:
-
2.0
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
HDMI cable type:
-
High Speed HDMI cable with Ethernet
-
Connector 2 form factor:
-
Straight
-
Connector 1 form factor:
-
Straight
-
Maximum resolution:
The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
-
4096 x 2160
-
Connector contacts plating:
What the connector contacts are covered with (layer on top).
-
Gold
-
Connector 1 gender:
The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.
-
Male
-
Connector 1:
This is the first connector in the device.
-
HDMI Type A (Standard)
-
Cable length:
How long the cable is.
-
2 m
-
Connector 2 gender:
The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.
-
Male
-
Connector 2:
This is the second connector in the device.
-
HDMI Type A (Standard)
