Digital protractor Linex 100414165 — transparent, 160 mm length, 1.6 mm thickness

The Linex digital protractor 100414165 is a transparent measuring tool with a 160 mm length and a 1.6 mm thickness, designed for electronic angle measurement and accurate transfer of angles. Made from glass-clear SAN, this compact instrument combines the functions of a ruler, set square and protractor in one. It is supplied as a single unit and is suitable for use in workshops, classrooms and technical drawing work where precise angle setting and repeatable measurements are required.

Advantages

The digital protractor offers accurate electronic angle readouts and a slim, transparent body that improves visibility of drawing surfaces and workpieces. The glass-clear SAN construction ensures dimensional stability while the bevel and yellow stripe improve contrast for easy scale reading. The antislide principle with a rubber strip on the back helps keep the tool firmly in place during measurement and transfer tasks. The combined functionality as ruler, protractor and set square reduces the need to switch tools during layout and marking tasks.

Suitable for

• Woodworking angle measurement and layout
• Metalworking and machining setups requiring angle transfer
• Technical drawing, drafting and classroom geometry exercises
• Workshop marking, template creation and inspection tasks

Key specifications

• Length: 160 mm
• Thickness: 1.6 mm
• Material: glass-clear SAN
• Functions: electronic angle measurement, ruler, protractor, set square
• Design features: bevel edge and yellow contrast stripe; anti-slip rubber backing

How to use

Place the digital protractor on the workpiece or drawing surface with the rubber-backed side against the material to minimize movement. Switch on the electronic angle function and align the appropriate edge or bevel with the reference line or face. Read the displayed angle or use the protractor to transfer the measured angle by marking along the ruler edge or bevel. Use the transparent body to align features underneath and the yellow stripe to improve visibility of the opposing scale. Clean the surface after use to maintain accurate contact between the rubber strip and the workpiece.

Usage recommendations

For best results use on flat, clean surfaces and avoid exposing the instrument to high temperatures or strong solvents; store flat to prevent warping and replace batteries for the electronic readout as specified by the manufacturer.
