Wireless doorbell LTC LXDZ1 with thermometer, AC 230V

LTC Wireless doorbell LXDZ1 ELECTRO is a wired chime unit with an integrated thermometer that operates from AC 230V and pairs with a battery-powered push button. The product combines visitor signalling and local temperature readout, offering up to 120 m range in open conditions and 36 selectable melodies. It is intended for residential and small commercial premises where mains power is available and a radio doorbell solution is required.

Advantages

The bell unit is mains-powered (AC 200–260V), eliminating the need for frequent battery replacement in the chime. The transmitter button uses a single 12V A23 battery, allowing simple, non-invasive installation without wiring. A built-in thermometer provides immediate ambient temperature information. Wireless communication at 433.93 MHz supports reliable pairing and a line-of-sight range of up to 120 meters, while 36 melody options permit ringtone selection to match user preference. The unit delivers a maximum sound level of 85 dB.

Suitable for

• Home entrances and interior calling
• Shops, restaurants and hotels
• Offices and warehouses
• Care settings and assistance for people requiring alerts

Key specifications

• Operating frequency: 433.93 MHz ±1 MHz
• Bell power supply: AC 200V–260V (230V nominal)
• Button power: 1 × 12V A23 battery
• Reception range: up to 120 m (ideal conditions)
• Sound: 36 selectable melodies
• Thermometer: built-in
• Volume: 85 dB

How to use

Install the chime unit near an AC mains outlet and plug it into the 230V supply. Insert a 12V A23 battery into the wireless button and mount the button at the desired entrance using screws or adhesive tape. Pair the button with the chime according to the included pairing procedure (pressing the button or following the unit’s pairing steps). Select a melody and adjust placement for optimal reception; the displayed temperature on the chime will indicate the local ambient temperature.

Usage recommendations

Place the chime in a central indoor location for best sound coverage and avoid metal obstructions between the button and receiver to maintain the specified reception range. Replace the button battery when signal strength or response reliability decreases, and keep the unit away from direct moisture and extreme temperatures.
