LED driver MEAN WELL LPV-150-24 Output power 151.2 W AC input 180-305 V

The MEAN WELL LPV-150-24 is a 150W single-output LED driver designed for LED lighting and LED moving sign applications. As a Class II power supply, it comes in a UL 94V-0 rated flame-retardant plastic enclosure and features an IP67 rating for use in dry, damp, and wet locations. This constant-voltage driver provides a 24V output and accepts an AC input range of 180–305 V. Its compact dimensions (63 mm × 191 mm × 37.5 mm) make it suitable for installations with limited space.

Advantages

The LPV-150-24 offers stable constant-voltage output at 24V with an output power around 151.2 W, wide AC input compatibility (180–305 V), and full protection against dust and water thanks to the IP67 enclosure. The Class II design eliminates the need for protective earth, and the UL 94V-0 flame-retardant housing improves safety in demanding environments. Its compact size simplifies mounting in confined or outdoor fixtures.

Suitable for

• LED strip lighting and LED modules requiring 24V constant voltage
• Outdoor and indoor LED signage and moving signs
• Floodlights and linear fixtures with space constraints
• Environments exposed to moisture or dust (IP67-rated installations)

Key specifications

• Model: MEAN WELL LPV-150-24 (MPN: LPV-150-24)
• Output power: 151.2 W
• Output voltage: 24 V (constant voltage)
• AC input voltage: 180–305 V
• Enclosure: UL 94V-0 flame-retardant plastic
• Ingress protection: IP67 (suitable for dry, damp, and wet locations)
• Dimensions: 63 mm × 191 mm × 37.5 mm

How to use

Install the LPV-150-24 in a location appropriate for its IP67 protection rating; it can be mounted indoors or outdoors where exposure to moisture or dust is expected. Connect the AC supply within the specified 180–305 V range to the input terminals, and wire the 24V output to the LED load ensuring correct polarity. Provide adequate ventilation around the housing and secure the unit using appropriate fasteners or brackets. Follow local electrical codes and disconnect power before wiring.

Usage recommendations

Use the driver within its rated output power and input voltage range, avoid covering the housing to maintain heat dissipation, and ensure connectors and cable glands maintain IP67 integrity when installed outdoors.
