Short description

The Mikrotik RB912UAG-5HPnD is a versatile motherboard designed for routers, supporting Wi-Fi 4 (802.11n) and IEEE 802.11a standards. It features a powerful AR9342 processor, Gigabit Ethernet ports, and a USB Type-A port. With a compact size of 105mm x 105mm and a weight of only 67g, it is energy efficient with a maximum power consumption of 14W and operates on a DC input voltage of 8-30V, making it ideal for various networking applications.

Available for order: 15 pcs.

Warranty: 2 Years

SKU: 971839

Learn more

Deliver the order:

{{ userCountryName }}

to the Customer Service Center at Kengaraga 2b, Riga

13.07.2026 {{selectedOffer.officeDeliveryString}}

free

All delivery methods Hide details

Customer service center

2b. Kengaraga str., Riga, Latvia, LV-1063

13.07.2026 {{selectedOffer.officeDeliveryString}}

free

Courier Delivery Please note that in case of a large parcel additional delivery costs may apply!

16.07.2026 {{selectedOffer.courierDeliveryString}}

From 4.99 € (Weight: 0.07 kg)

Parcel couriers

Latvijas Pasts pakomāts / Unisend / DPD Paku skapis / Omniva / Venipak Pickup / Venipak Locker / Latvijas Pasts nodaļa

16.07.2026 {{selectedOffer.parcelStationDeliveryString}}

From 1.99 €

More about delivery methods

Payment Methods:

Bank transfer

More about payment methods

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The RB912UAG-5HPnD is a compact motherboard for routers that supports Wi‑Fi 4 (802.11n) and IEEE 802.11a. It integrates a high‑power wireless card and provides an additional miniPCIe slot for a secondary 802.11 wireless card or a 3G modem. The board includes a Gigabit Ethernet port to take advantage of higher wireless speeds and features built‑in 16 kV ESD protection on both the Ethernet and MMCX antenna ports. Note: the US variant (RB912UAG-5HPnD-US) is factory locked to 5170–5250 MHz and 5725–5835 MHz; this lock cannot be removed. The international variant supports 5150–5875 MHz, subject to local regulations.

Advantages

Small form factor and low weight make the RB912UAG-5HPnD suitable for compact router builds and installations with limited space. Integrated high‑power wireless and an extra miniPCIe slot increase flexibility for adding a second radio or cellular connectivity. Gigabit Ethernet maximizes throughput for 802.11n links, and the 16 kV ESD protection on Ethernet and MMCX ports improves durability in environments prone to electrostatic discharge.

Suitable for (tasks / use cases)

Custom router or access point projects
Wireless links using 802.11n or 802.11a
Deployments needing a secondary radio or 3G backup via miniPCIe
Environments requiring robust ESD protection on ports

Key specifications

Wireless standards: IEEE 802.11n (Wi‑Fi 4), IEEE 802.11a
Processor: AR9342 (integrated on board)
Interfaces: Gigabit Ethernet, USB Type‑A, MMCX antenna connectors, miniPCIe slot
ESD protection: 16 kV on Ethernet and MMCX ports
Frequency range: RB912UAG-5HPnD (INT) 5150–5875 MHz; RB912UAG-5HPnD-US locked to 5170–5250 MHz and 5725–5835 MHz
Power: DC input 8–30 V; max power consumption 14 W
Dimensions and weight: 105 × 105 mm, 0.067 kg

How to use

Install the RB912UAG-5HPnD into a compatible router chassis or mount it per the manufacturer’s mechanical guidelines. Attach external antennas to the MMCX connectors and connect network equipment to the Gigabit Ethernet port. If a secondary radio or 3G module is required, install the appropriate miniPCIe card into the expansion slot and secure any required antenna connections. Supply DC power within the 8–30 V range and configure networking and wireless parameters via the router operating system or management interface.

Usage recommendations

Operate the device within the legal frequency ranges for your country; use the international or US variant according to local regulatory restrictions. Ensure proper grounding and follow ESD handling procedures during installation to preserve the built‑in protection features.

Specifications

Weight:: 0.067 kg
Networking standards:: IEEE 802.3af, IEEE 802.11n, IEEE 802.11a

All features

Storage capacity:: 64 MB
Number of SIM cards:: 1
DC input voltage:: 8 - 30
License level:: 4
Power over Ethernet (PoE) ports quantity:: 1
Storage media:: Flash
Device compatibility:: Router
USB ports quantity:: 1
Basic switching RJ-45 Ethernet ports type:: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity:: 1
Product type:: Motherboard
Temperature monitoring:: Yes
Power over Ethernet (PoE) voltage range:: 8 - 30
Voltage monitoring:: Yes
Top Wi-Fi standard:: Wi-Fi 4 (802.11n)
Power connector:: DC-in jack
USB port type:: USB Type-A

Performance

Processor frequency:: 600 MHz
Internal memory:: 64 MB
Processor model:: AR9342
Processor cores:: 1

Power

Power consumption (max):: 14 W

Mobile network

SIM card type:: MiniSIM
SIM card slot:: Yes

Weight & dimensions

Weight:: 0.067 kg
Width:: 105 mm
Depth:: 105 mm

Design

Reset button:: Yes

Features

Networking standards:: IEEE 802.3af, IEEE 802.11n, IEEE 802.11a
