Digital Caliper MODECO MN-85-100 — 150 mm measuring range, 0.01 mm resolution

MODECO MN-85-100 is a digital caliper designed for precise dimensional measurements with a 150 mm measuring range and 0.01 mm resolution. The instrument performs external, internal and depth measurements and displays values on an electronic LCD for immediate reading. Its compact, portable construction makes it suitable for workshop environments, engineering tasks and hobby projects where accurate, repeatable measurements are required.

Advantages

The digital caliper offers a high-resolution 0.01 mm display that reduces reading errors and speeds up measurement tasks. A clear electronic readout provides fast numeric results without manual interpretation of scales. The caliper’s robust jaws and finely finished sliding mechanism enable stable contact with measured surfaces, while its compact size allows easy handling and transport. Battery-powered electronics ensure consistent performance across multiple measurement types.

Suitable for

• External diameter and length checks of parts and components
• Internal diameter measurements of holes and bores
• Depth measurements of slots, recesses and steps
• Quality control inspections and part verification in workshops
• Hobbyist and DIY dimensional checks for model making and repairs

Key specifications

• Measuring range: 0–150 mm
• Resolution: 0.01 mm
• Measurement types: external, internal, depth
• Display: electronic LCD for numeric readout
• Power: battery powered (replaceable cell)
• Construction: metal sliding scale with fixed and movable jaws
• Portability: compact and lightweight for easy handling

How to use

Clean measuring surfaces on both the caliper and the workpiece before use to ensure accurate readings. Switch on the display and zero the instrument at the fully closed position if required. For external measurements, place the object between the jaws and slide the movable jaw until it contacts the part without excessive force. For internal measurements, use the smaller jaws to contact opposing internal surfaces. For depth measurements, extend the depth probe into the feature and read the value from the display. Record measurements directly from the LCD and switch off the caliper when not in use to conserve battery life.

Usage recommendations

Store the caliper in a protective case when not in use and avoid exposing it to heavy impacts, dust or moisture. Periodically check calibration and replace the battery promptly when display dimming or inconsistent readings occur. Use light, steady contact pressure while measuring to prevent deformation of delicate parts and to maintain repeatability.
