Brush holder set for TF1201 router — No name, 2 pieces (parts 54, 55)

Replacement brush holder set for TF1201 router, brand No name, comprising two holders corresponding to parts 54 and 55. These brush holders secure the motor carbon brushes in the commutator assembly, maintaining stable electrical contact and supporting reliable motor operation during cutting and routing tasks. The set is intended for repair and routine maintenance of TF1201 units that require the specific holder shape and mounting points.

Advantages

The brush holder set is supplied as two matched pieces to fit the TF1201 router’s commutator layout, enabling direct replacement without modification. Manufactured to match the original holder geometry, the parts promote consistent brush pressure and alignment, which helps reduce sparking and uneven wear on carbon brushes. Using the correct holders preserves motor efficiency and simplifies servicing by restoring correct brush positioning.

Suitable for

• Repairing TF1201 routers with worn or damaged brush holders
• Routine maintenance to restore proper brush alignment and contact
• Replacing holders after brush replacement to ensure correct fit

Key specifications

• Quantity: 2 pieces (matched set for commutator assembly)
• Compatibility: designed for TF1201 router models requiring parts 54 and 55
• Function: holds motor carbon brushes in fixed position for electrical contact
• Material: durable insulating and conductive-compatible components suitable for brush mounting
• Mounting: shaped to align with factory mounting points and brush springs

How to use

Disconnect the router from power and remove the motor housing to access the commutator and brush assemblies. Remove the old holders by detaching any securing screws or clips and carefully release the brush springs and carbon brushes. Install the new holders in the same orientation as the originals, secure them to the mounting points, reinsert the carbon brushes and springs, and verify correct seating and free movement of the brushes. Reassemble the housing and perform a brief no-load run to check for smooth motor operation and minimal sparking.

Usage recommendations

Always replace brush holders in matched pairs when both positions show wear, and use brushes of the recommended grade and length for the TF1201 router. Perform inspections periodically and clean the commutator surface before reassembly to ensure optimal electrical contact and extend motor life.
