Jigsaw stand for VZR401 (model YVZR41SS) — replacement jigsaw motor mount

Replacement jigsaw stand for VZR401 is a motor mounting bracket designed to restore secure attachment and correct alignment between the motor and cutting unit of compatible VZR401 jigsaw models. The part serves as the structural interface that holds the motor in the correct position relative to the blade assembly, ensuring stable operation after repair or maintenance.

Advantages

This motor mount provides precise alignment to reduce wobble and maintain consistent blade travel. Constructed to match the original fitting points of VZR401-compatible jigsaws, it facilitates straightforward replacement without the need for modifications. The design supports reliable attachment and helps preserve the intended distance and angle between motor and cutting mechanism for predictable cutting performance.

Suitable for

• Repairing a VZR401-series jigsaw with a damaged or worn motor mount
• Maintenance tasks requiring replacement of the motor-to-cutting-unit interface
• Restoring correct motor alignment after impact or internal disassembly

Key specifications

• Function: motor mounting bracket for jigsaw
• Compatibility: designed for use with VZR401-compatible jigsaw models
• Role: provides fixed attachment points and alignment between motor and blade assembly
• Material characteristics: engineered for structural stability under normal jigsaw operating conditions

How to use

Before installation, disconnect power and remove the jigsaw battery or unplug the power cord. Disassemble the jigsaw housing and detach any components that obstruct access to the motor mount according to the service manual for your VZR401 model. Remove the damaged mount by undoing its fasteners, align the replacement stand with the original mounting points, and secure it with the appropriate screws. Reinstall the motor and any previously removed components, verify mechanical alignment and clearances, then reassemble the housing and test the tool at low speed to confirm correct operation.

Usage recommendations

Use genuine or compatible fasteners of the correct size and torque values to secure the mount. Perform a visual check of alignment and blade tracking after installation, and tighten fasteners incrementally to avoid misalignment. If uncertain about disassembly or reassembly, consult a qualified service technician or the tool’s maintenance documentation.
