Cardan Joint ZA-104MS universal joint coupling model ZA-104MS, No name

The Cardan joint ZA-104MS universal joint coupling is a mechanical component designed to transmit torque between shafts that are not perfectly aligned. It accommodates angular misalignment while maintaining rotational motion transfer, making it suitable for applications in drive shafts, steering linkages and general power transmission in industrial and automotive repair contexts. The design focuses on providing a flexible connection that reduces stress on connected components while preserving torque delivery.

Advantages

This universal joint coupling offers a compact solution for transmitting rotational forces across misaligned shafts. Its construction provides smooth angular compensation and reliable torque transfer under typical operating loads. The component is compatible with common mechanical assemblies, is simple to install when shaft dimensions match, and helps extend the service life of connected driveline elements by reducing bending moments and localized wear.

Suitable for

• Drive shaft assemblies in light machinery and vehicles
• Steering linkage repairs and replacements
• Power transmission between offset or angled shafts in industrial equipment
• Prototyping and mechanical repairs where a flexible rotational joint is required

Key specifications

• Type: Cardan (universal) joint
• Function: Transmits torque between misaligned rotating shafts
• Application areas: Automotive repair, industrial equipment, mechanical assemblies
• Design: Cross-and-yoke style articulation (standard universal joint geometry)
• Installation: Requires matching shaft diameters and appropriate fastening method for secure coupling

How to use

Select a ZA-104MS universal joint coupling that matches the shaft diameters and fitment requirements of your assembly. Prepare shafts by cleaning contact surfaces and removing burrs. Align the joint with the mating shafts and secure it using the appropriate fasteners or clamps recommended for your shaft type. After installation, rotate the assembly slowly to verify smooth operation and check for any binding or excessive play. Perform periodic inspections to ensure retaining elements and lubrication (if applicable) remain in good condition.

Usage recommendations

Ensure compatibility of shaft diameter, spline or fastening type and working angles before installation. Avoid exceeding the joint's intended torque and articulation limits. Where applicable, follow lubrication guidelines or service intervals recommended for universal joints to maintain performance and reduce wear.
