Pafana NNBE 1212 S30 NOZ TOK.ISO 6 R – cutting tool holder ISO6R, model ISO6R1212P30

Pafana NNBE 1212 S30 NOZ TOK.ISO 6 R (model ISO6R1212P30) is a precision cutting tool holder designed for turning and milling setups that accept the ISO6R interface. The holder has a compact 12x12 mm shank and S30 seating for the cutting insert, providing stable tool positioning and consistent clamping for metalworking processes in both CNC and manual lathes. Its configuration supports reliable chip evacuation and accurate repeatability across multiple operations.

Advantages

The tool holder offers a space-saving 12x12 mm shank and a standardized S30 seating that ensures consistent insert placement and improved stability during cutting. Its ISO6R interface compatibility enables easy integration with machines and toolposts designed for this standard. The holder's design promotes efficient chip flow and steady clamping, which contributes to predictable machining results and longer insert life when used within recommended cutting parameters.

Suitable for

• Turning operations on CNC and manual lathes that accept ISO6R tool holders
• Light to medium milling tasks where a compact 12x12 mm holder is required
• Applications requiring repeatable clamping and precise tool positioning
• Metalworking with steel, stainless steel, cast iron, and non-ferrous alloys under appropriate cutting conditions

Key specifications

• Shank size: 12 mm x 12 mm (square)
• Insert seating: S30
• Interface: ISO6R compatible
• Tool orientation: right-hand (R) configuration
• Primary application: turning and light milling

How to use

Mount the holder into the machine tool or toolpost that accepts ISO6R interface, ensuring the seating and clamping surfaces are clean and free of debris. Fit the appropriate S30 insert and tighten the clamping screw to the manufacturer's recommended torque to achieve secure and repeatable positioning. Verify correct tool projection and clearances before starting the cut, and adjust feed and speed according to the workpiece material and insert grade.

Usage recommendations

Use the holder with inserts and cutting parameters matched to the workpiece material. Regularly inspect the seating and clamping surfaces for wear or damage and clean chips from the holder to maintain stable clamping. Avoid exceeding recommended cutting forces for a 12x12 mm shank to prevent deflection; for heavy cuts select a larger shank profile or different holder design.
