Perfexim pipe elbow fitting 32x1, female threaded U-type (Perfexim 734)

The Perfexim pipe elbow fitting 32x1, female threaded U-type (Perfexim 734) is a compact 90° elbow designed to join and redirect pipe runs with female threaded connections. It is intended for use in plumbing and heating systems where compatible 32x1 threaded pipes and fixtures need a reliable, space-saving threaded junction. The U-type shape provides a right-angle change of direction while maintaining a secure threaded interface for standard threaded pipe fittings.

Advantages

This elbow fitting offers a compact footprint that simplifies routing in tight installations and reduces the need for additional adapters. The female threaded connection allows direct joining with male-threaded pipes or accessories, enabling straightforward assembly and disassembly. Its consistent 90° geometry ensures predictable flow direction and alignment in piping layouts, while the threaded connection provides a mechanically strong joint appropriate for typical plumbing and heating pressures.

Suitable for

• Domestic and commercial plumbing systems with compatible 32x1 threaded pipes
• Heating installations and radiator connections requiring a 90° change of direction
• Repair or reconfiguration of existing threaded pipe runs

Key specifications

• Connection type: female threaded, 32x1 size
• Shape: U-type 90° elbow
• Intended use: plumbing and heating piping junction
• Mounting: inline threaded assembly with compatible male-threaded components
• Design: compact elbow for space-constrained installations

How to use

Prepare the mating male-threaded pipe or fitting by cleaning threads and applying an appropriate thread sealant or tape compatible with the fluid and system pressure. Align the male thread with the female thread of the Perfexim 734 elbow and hand-start the connection to ensure correct engagement. Tighten with a suitable wrench to the torque recommended for the pipe material and thread type, avoiding over-tightening. Inspect the assembled joint for leaks and perform a pressure test according to applicable plumbing or heating system standards before placing the system into service.

Usage recommendations

Use compatible 32x1 threaded components and suitable thread sealants for the intended medium (water, heating fluid). Verify material compatibility and pressure ratings of adjacent components to ensure a safe, leak-free installation. In systems with temperature cycling or vibration, periodically inspect threaded joints and retighten if necessary following manufacturer and local code guidelines.
