Pixel pitch:
This is the parameter of a picture tube, which specifies the shortest distance between two dots of the same colour. The principle is: the smaller the dot pitch, the better sharpness of image.
-
0.493 x 0.493
-
Contrast ratio (typical):
The difference in light intensity between the brightest white and the darkest black.
-
1200:1
-
Viewing angle, horizontal:
Maximum horizontal angle at which a display can be viewed with acceptable visual performance.
-
178 °
-
Viewing angle, vertical:
Maximum vertical angle at which a display can be viewed with acceptable visual performance.
-
178 °
-
Aspect ratio:
The aspect ratio is the ratio of the width of a shape to its height. For example, 4:3 is common for standard displays and 16:9 is the ratio for Widescreen TV.
-
16:9
-
Power consumption (typical):
Amount of power consumed by this model, often expressed in watts (W). Typical values that manufacturers give are power consumption when off, standby/suspended mode, typical use, maximum usage.
-
175 W
-
Mean time between failures (MTBF):
Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.
-
50000 h
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-20 - 60
-
Package weight:
Weight of the packaged product.
-
70000 g
-
Display diagonal:
Size of the display for this product, measured diagonally, usually in inches.
-
86 "
-
Processor manufacturer:
The manufacturer that produced the processor.
-
ARM
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 40
-
Ethernet LAN:
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
-
Yes
-
Display brightness:
Brightness is the amount of radiating light emitted from the screen. The brightness rating is measured in candellas per square meter, commonly known as 'nits'.
-
400 cd/m²
-
Height:
The measurement of the product from head to foot or from base to top.
-
1170.8 mm
-
Response time:
The response time is the time difference between the moment that a source (for example a video card) sends a signal and that equipment (for example a monitor) receives or display the signal. (Used abbreviations: R/F = Rise and Fall.)
-
8 ms
-
Display resolution:
The number of distinct pixels in each dimension that can be displayed. It is usually quoted as width × height, with the units in pixels: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels. The higher the number of pixels, the sharper the image.
-
3840 x 2160
-
Width:
The measurement or extent of something from side to side.
-
1957 mm
-
Depth:
The distance from the front to the back of something.
-
97.1 mm
-
Remote control included:
Component of an electronics device, most commonly a television set, DVD player and home theater systems originally used for operating the device wirelessly from a short line-of-sight distance.
-
Yes
-
USB connector type:
The type of USB connector/port that this product has.
-
USB Type-A, USB Type-C
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Cables included:
-
AC, USB Type-A to USB Type-B
-
Number of built-in speakers:
-
2
-
RMS rated power:
RMS (Root mean square) is a measure of the continuous power required by a device, in particular audio amplifiers and loudspeakers.
-
40 W
-
Power consumption (standby):
The amount of electricity that is consumed when the product is on standby.
-
0.5 W
-
Processor family:
A family of processors is a group of processors produced by one company over a short period of time e.g. Intel Pentium processors.
-
ARM Cortex
-
Ethernet LAN (RJ-45) ports:
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
-
1
-
Built-in speaker(s):
The device contains speaker(s) to produce sound.
-
Yes
-
Operating system installed:
Type of operating system on a device e.g. IOS on Apple devices, Android for mobile devices.
-
Android 14
-
Wi-Fi:
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
-
Yes
-
Placement supported:
Where the product can be placed e.g. indoor/outdoor, horizontal/vertical.
-
Indoor
-
PC Audio in:
The socket (port) for the PC audio input.
-
Yes
-
Audio (L/R) out:
The two sockets (ports) for transmitting left audio signal (white cable) and right audio signal (red cable).
-
1
-
Component video (YPbPr/YCbCr) in:
The number of sockets (ports) for RF (radio frequency) connections into the product.
-
1
-
HDMI ports quantity:
The number of sockets (ports) for HDMI connections. HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from a HDMI-compliant device ("the source device") to a compatible computer monitor, video projector, digital television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
-
3
-
Manual:
-
Yes
-
Quick start guide:
Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.
-
Yes
-
Panel mounting interface:
The product can be used wih VESA mounting interfaces.
-
800 x 600
-
Width (with stand):
-
1957 mm
-
Display diagonal (metric):
This is the size of the display screen, measured diagonally.
-
218.44 cm
-
Height (with stand):
-
1170.8 mm
-
Depth (with stand):
-
97.1 mm
-
Supported graphics resolutions:
The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
-
800 x 600 (SVGA), 848 x 480, 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 960, 1360 x 768 (WXGA), 1366 x 768, 1600 x 1200, 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3840 x 2160
-
Supported video modes:
The video modes that can be displayed by the device.
-
480i, 480p, 720p, 1080i, 1080p, 2160p
-
Batteries included:
-
Yes
-
Touchscreen:
A screen of a laptop, smartphone, etc., that responds to touch so you can control the interface using your fingers.
-
Yes
-
Product design:
The creation of a plan or convention for the construction of an object or a system.
-
Interactive flat panel
-
HDMI version:
-
2.0
-
Contrast ratio (dynamic):
A property of a display system, defined as the ratio of the luminance of the brightest color (white) to that of the darkest color (black) that the system is capable of producing.
-
500000:1
-
DisplayPorts quantity:
Number of DisplayPorts. A DisplayPort is a digital display interface developed by the Video Electronics Standards Association (VESA). The interface is primarily used to connect a video source to a display device such as a computer monitor, though it can also be used to carry audio, USB, and other forms of data.
-
1
-
Built-in processor:
Whether or not a processor is built into the device.
-
Yes
-
Bezel width (side):
-
16.4 mm
-
Bezel width (top):
-
17.3 mm
-
Bezel width (bottom):
-
44.9 mm
-
Stylus pen:
-
Yes
-
AC input frequency:
-
50 - 60
-
AC input voltage:
The voltage of the AC electricity that is inputted into the product.
-
100 - 240
-
VGA (D-Sub) input ports:
Sockets in the device for VGA (D-Sub) inputs, which are sockets with 15 holes. The 15-pin VGA connector is found on many video cards, computer monitors, and high definition television sets.
-
1
-
Display technology:
The technology used in the display e.g. plasma, LED.
-
LED
-
Processor architecture:
-
ARM Cortex-A53+Cortex-A73
-
Anti-glare screen:
Always gives an optimal view, even in direct sunlight.
-
Yes
-
Display weight:
-
51250 g
-
Native aspect ratio:
The aspect ratio is the ratio of the width of an image to its height. The native aspect ratio is the one which the projector/display is particularly designed for. Images shown in native aspect ratio will utilize the entire resolution of the display and achieve maximum brightness. Images shown in other than native aspect ratio will always have less resolution and less brightness than images shown in native aspect ratio.
-
16:9
-
HD type:
Type of supported High Definition (e.g. Full HD, 4K Ultra HD).
-
4K Ultra HD
-
USB ports quantity:
-
4
-
RS-232C:
-
Yes
-
Panel life:
The length of time that the panel can be used for.
-
50000 h
-
Number of speaker outputs:
-
1
-
VESA mounting:
-
Yes
-
USB port:
The device features a socket into which a USB cable can be plugged.
-
Yes
-
Display number of colours:
-
1.07 billion colours
-
Number of stylus pens:
-
2
-
HDMI input ports quantity:
-
3
-
HDMI output ports quantity:
-
1
-
Bluetooth audio:
-
Yes
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
CB, CE, EAC, EMF, ETL, Federal Communications Commission (FCC), RoHS
