Time Relay Module PULSAR AWZ-526 — DIN-mount, programmable time relay module

PULSAR AWZ-526 is a DIN-rail mountable time relay module designed to provide programmable timing functions for electrical control panels and automation systems. The module delivers delayed switching, pulse generation and cyclic timing capabilities to control relays or circuits. Its compact form factor and DIN compatibility make it suitable for integration into industrial, commercial and building automation installations where timed control is required.

Advantages

The module offers flexible programmable time functions and clear integration with standard DIN-rail mounting for straightforward installation in control cabinets. It supports multiple timing modes to cover a range of control scenarios and reduces the need for separate timer devices. The device’s design focuses on predictable timing performance and compatibility with common relay inputs and outputs used in automation systems.

Suitable for

• Delayed switching of lighting, motors or pumps in electrical panels
• Pulse generation for triggering relays and control circuits
• Cyclic timing for periodic control tasks in building automation
• Integration into industrial control cabinets and distribution boards

Key specifications

• Mounting: DIN-rail compatible
• Functionality: programmable time relay with delayed, pulse and cyclic modes
• Control output: relay/contact output suitable for switching external circuits
• Form factor: compact module for panel installation
• User interface: settings for selecting timing mode and adjusting time range

How to use

Install the PULSAR AWZ-526 into a standard DIN-rail rail inside the control cabinet and connect supply and control wiring according to the system’s wiring diagram. Select the required timing mode and set the desired time interval using the module’s controls. Verify correct wiring and perform functional tests to confirm delayed switching, pulse generation or cyclic operation before placing the circuit into regular use. Follow electrical safety procedures and isolate power when making wiring changes.

Usage recommendations

Use the module within the voltage and environmental specifications of the control system, and ensure relay contacts are rated for the load being switched. For reliable long-term operation, avoid exposure to excessive dust, vibration or moisture and perform periodic functional checks as part of routine panel maintenance.
