Power distribution terminal PULSAR AWZ-579 – wired power connection block for security and CCTV systems

PULSAR AWZ-579 is a compact power distribution terminal engineered for wired power connections in security, alarm and CCTV installations. The device provides a centralised point for routing and splitting DC power lines, allowing installers to organise wiring, reduce clutter and maintain reliable power feed to cameras, sensors and control panels. Designed for professional installation and maintenance, the terminal supports tidy cable management and straightforward connection procedures in both new and retrofit projects.

Advantages

The AWZ-579 offers a space-saving design that simplifies on-site wiring and reduces the number of individual power runs. Its terminal block format enables secure, low-resistance connections, which contributes to stable DC power distribution across multiple devices. The product facilitates quicker installation and easier troubleshooting by grouping power outputs in one accessible location. Materials and construction are chosen to meet typical requirements of security and CCTV environments where reliability and consistent contact are important.

Suitable for

• Wiring power to CCTV cameras in residential and commercial surveillance systems
• Power distribution to sensors and detectors in alarm installations
• Centralising DC power feeds for access control panels and peripheral devices
• Professional installation and service work in security system cabinets and enclosures

Key specifications

• Function: DC power distribution and terminal block for multiple outputs
• Ports: Multiple terminal outputs for parallel power connections
• Compatibility: Designed for 12 V / 24 V typical security and CCTV power systems (verify system voltage before installation)
• Mounting: Suitable for installation inside equipment cabinets or housings used in security systems
• Construction: Compact module intended for organised cable routing and mechanical stability of connections

How to use

Install the PULSAR AWZ-579 inside the system cabinet or enclosure near the main DC power source. Connect the incoming DC power positive and negative conductors to the designated input terminals, observing correct polarity and ensuring power is switched off during wiring. Run output leads from the terminal outputs to cameras, sensors or control panels, making secure terminations and maintaining appropriate cable routing to avoid strain or interference. After wiring, restore power and verify voltage at each output and correct operation of connected devices.

Usage recommendations

Before installation, confirm system voltage and current requirements and use appropriately sized conductors and fuses or circuit protection at the power source. Keep connections tight and inspect periodically for corrosion or looseness. For best results, route signal and power cables separately where possible and follow local electrical and safety regulations when integrating the terminal into security or CCTV systems.
