Relpol PIR6WT-1Z-24VAC/DC-R Slim Multifunction Time Relay 6A 24V AC/DC

The Relpol PIR6WT-1Z-24VAC/DC-R is a high-performance, slim-profile multifunction time relay engineered for precise timing control in industrial automation and electrical systems. This compact device is designed to facilitate reliable switching operations, offering a versatile solution for managing time-dependent processes within a narrow footprint. Its robust construction ensures consistent performance in demanding environments where space efficiency is critical.

Advantages

The primary advantage of this relay is its slim design, which allows for high-density mounting on DIN rails, significantly saving space in control cabinets. It offers exceptional flexibility through its multifunction capabilities, enabling users to configure various timing modes to suit specific operational requirements. The wide timing range, spanning from one second to ten days, provides extensive versatility for both short-interval and long-duration applications. Furthermore, the 6A contact rating ensures reliable switching for a variety of electrical loads, while the universal 24V AC/DC power supply simplifies integration into existing control circuits.

Suitable for

• Industrial automation and control systems
• Lighting control and building management
• Process timing in manufacturing machinery
• HVAC system control
• Delay-on and delay-off switching applications

When it may not be suitable

This relay is not intended for high-power switching applications exceeding its 6A contact rating. It is also not suitable for environments requiring specialized ingress protection against water or dust, as it is designed for installation within protected control enclosures.

Key specifications

• Contact rating: 6A
• Supply voltage: 24V AC/DC
• Timing range: 1 second to 10 days
• Mounting type: DIN rail
• Profile: Slim design

How to use

The relay is designed for standard DIN rail mounting within an electrical enclosure. Once securely mounted, connect the 24V AC/DC power supply to the designated input terminals. Configure the desired timing mode and duration using the integrated adjustment controls on the front panel. Ensure all wiring is performed according to the local electrical standards and that the load connected to the output contacts does not exceed the specified 6A current rating.

What to consider before purchase

• Verify that your control system voltage matches the 24V AC/DC requirement.
• Ensure the load current does not exceed 6A.
• Check available space on your DIN rail to accommodate the slim profile.
• Confirm the required timing functions align with the relay's multifunction capabilities.

Usage recommendations

Always ensure the power is disconnected before performing any wiring or adjustments to the relay. Periodically inspect the terminal connections to ensure they remain tight and free from oxidation to maintain optimal electrical conductivity.
