Bus bar kit Rittal SV 9686.300 — polyamide housing, black, pack of 2

Rittal SV 9686.300 is a one‑pole bus bar holder kit designed to support and insulate neutral (N) or PEN conductors in switchgear and distribution enclosures. Supplied as a pack of two, each holder features a black polyamide housing that provides mechanical support and electrical insulation for bus bars or single conductors used in electrical distribution installations.

Advantages

The polyamide housing offers high electrical insulation and mechanical stability while remaining resistant to common environmental influences encountered in electrical cabinets. Its compact, one‑pole design simplifies mounting in tight spaces and helps maintain clear conductor separation. Supplied as a pack of two, the kit reduces the need for separate procurement of individual holders and supports consistent material and appearance across installations.

Suitable for

• Mounting and securing 1‑pole neutral (N) conductors in distribution and control panels
• Support and insulation of PEN conductors in switchgear housings
• Use where compact, insulated single‑pole holders are required in electrical enclosures
• Replacement or standardization of conductor supports in indoor electrical distribution systems

When it may not be suitable

This bus bar holder kit is intended for single‑pole support of neutral or PEN conductors and is not designed as a multi‑pole bus bar assembly or for direct connection of live three‑phase conductors. It is optimized for use inside electrical cabinets and may not be appropriate for exposed outdoor installations or locations requiring additional environmental protection or different material properties.

Key specifications

• Housing material: polyamide (black)
• Configuration: one‑pole holder
• Quantity: pack of 2 holders
• Function: mechanical support and electrical insulation for neutral/PEN conductors
• Intended mounting: for use in switchgear and distribution enclosures

How to use

Install the holders at the required positions within the switchgear or distribution enclosure to support the conductor path. Secure the holder to the mounting surface according to the cabinet manufacturer's instructions and route the neutral or PEN conductor into the holder so that it is held firmly without excessive strain. Ensure that all electrical work is carried out by a qualified electrician and that the installation is de‑energized during mounting. Verify clearances and secure fastening to maintain insulation and mechanical stability.

What to consider before purchase

• Confirm that a one‑pole holder is suitable for the conductor type and number of conductors you need to support
• Check compatibility with the mounting method and space available inside your enclosure
• Verify material requirements (polyamide) for temperature, chemical exposure, or regulatory constraints in your application
• Ensure quantity (pack of 2) meets your project needs

Usage recommendations

For reliable performance, use these holders only inside appropriately rated enclosures, follow local electrical codes, and perform installation and inspection by qualified personnel to ensure correct conductor clamping and electrical safety.
