RJ45 Socket Meridian 9096 7062 — RJ45 network socket for keystone wall plates

Meridian 9096 7062 is an RJ45 network socket designed for keystone-style wall plates and modular installation panels. The socket provides a standard female RJ45 connector that accepts terminated Ethernet plugs, enabling the creation of neat, accessible network outlets in rooms, offices and data cabinets. Intended for in-wall or panel mounting, the unit simplifies cable management and allows flexible positioning of network points using compatible keystone wall plates and modules.

Advantages

The Meridian RJ45 socket offers a compact keystone form factor that fits common wall plates and patch panels, enabling straightforward replacement or addition of network outlets. Its standardized RJ45 female connector ensures compatibility with Cat5e/Cat6 terminated cables and typical Ethernet patch leads. The module enables modular installations that reduce wall clutter and centralize cabling for easier maintenance and testing.

Suitable for

• Residential and commercial wall plate installations
• Office network outlets and meeting rooms
• Patch panels and modular data cabinets
• Retrofit projects where keystone modules are required

Key specifications

• Connector type: female RJ45 keystone module
• Mounting: keystone-style wall plate or module mounting
• Compatibility: fits standard keystone openings in wall plates and panels
• Use case: termination point for Ethernet patch cords and terminated network cables

How to use

Install the Meridian RJ45 socket into a compatible keystone wall plate or module frame by snapping the module into the plate opening until it locks. Terminate the incoming Ethernet cable on a compatible coupler or use a pre-terminated patch cord to plug into the RJ45 female connector. Once mounted in the wall plate or panel, secure the plate to the electrical box or mounting bracket and label the outlet if required for identification.

Usage recommendations

Use the socket with appropriately rated Ethernet cables and connectors that match the network category in use. Avoid exposing the module to excessive moisture or mechanical stress during installation. For structured cabling projects, plan port labeling and patching layout before finalizing wall plate arrangements to ensure consistent network mapping.
