Button Schneider Electric XB7 — control push button, IP20, 35 g, model XB7NS8445

Schneider Electric XB7 control push button is a compact mechanical operator control designed for use on control panels, operator stations and machinery interfaces. The unit is built to provide simple, tactile switching for start/stop, mode selection and other operator inputs. With IP20 protection and a lightweight construction, this push button is intended for indoor, panel-mounted applications where a small, reliable manual actuator is required.

Advantages

The XB7 push button offers compact dimensions and low mass, making it easy to install in confined panel spaces and compatible with a wide range of industrial control enclosures. Its mechanical design delivers a clear tactile feedback for reliable operator action. The IP20 protection rating is appropriate for protected indoor environments and control cabinets. The product’s standardized form factor supports straightforward replacement and integration with existing control modules and operator stations.

Suitable for

• Operator panels and control stations in industrial equipment
• Machine control interfaces for start/stop and mode selection
• Electrical cabinets and panel-mounted switch assemblies
• Applications requiring a lightweight, compact push button for manual input

Key specifications

• Protection class: IP20, suitable for indoor panel environments
• Actuator type: mechanical push button for manual switching
• Weight: approximately 35 g, enabling easy mounting and minimal load on panel supports
• Mounting style: panel-mounted operator control form factor compatible with standard cutouts
• Intended environment: indoor use within control cabinets and protected industrial panels

How to use

Mount the push button into the appropriate panel cutout and secure it according to the panel manufacturer’s instructions and the device’s mounting scheme. Connect the electrical contacts to the control wiring following the control circuit design, ensuring power is isolated during installation. Use the push button as a manual input for switching functions such as start/stop, emergency reset, or mode change. Verify operation after wiring by exercising the button and checking the corresponding control outputs or indicators.

Usage recommendations

For reliable long-term performance, install the push button in a clean, dry cabinet or protected panel to match its IP20 rating. Avoid exposure to dust, water spray or corrosive atmospheres. Confirm mechanical compatibility with the panel cutout and ensure wiring and mounting follow local electrical codes and the equipment’s control schematic.
