Package weight:
Weight of the packaged product.
-
163 g
-
Height:
The measurement of the product from head to foot or from base to top.
-
100 mm
-
Package depth:
The distance from the front to the back of the packaging.
-
127 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
40 mm
-
Package width:
The distance from one side of the packaging to the other.
-
111 mm
-
Minimum order quantity:
-
1 pc(s)
-
Timer duration (minimum):
-
0.05 s
-
Battery included:
-
No
-
Timer duration (maximum):
-
100 s
-
Maximum order quantity:
-
1 pc(s)
-
Compliance certificates:
Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.
-
CE, RoHS, REACH
-
Pluggable on auxiliary contact block:
-
No
-
Semiconductor output:
-
No
-
Function star-delta:
-
No
-
Function delay-on energization:
-
Yes
-
Number of outputs (delayed, change-over contact):
-
2
-
Function floating contact on energization:
-
Yes
-
Function delay on de-energization:
-
No
-
Function floating contact on de-energization:
-
Yes
-
Number of outputs (undelayed, normally open contact):
-
0
-
Function pulse shaping:
-
Yes
-
Number of outputs (undelayed, normally closed contact):
-
0
-
Number of outputs (delayed, normally closed contact):
-
0
-
Number of outputs (undelayed, change-over contact):
-
0
-
Number of outputs (delayed, normally open contact):
-
0
-
Remote operation possible:
-
No
-
Suitable as remote control:
-
No
-
Function flashing (starting with pause, fixed time):
-
Yes
-
Function flashing (starting with pulse, fixed time):
-
Yes
-
Clock function (starting with pause, variable):
-
No
-
Clock function (starting with pulse, variable):
-
No
-
Outputs (reversible delayed/undelayed):
-
No
-
Actuating voltage type:
-
AC/DC
-
Electrical connection type:
-
Spring clamp connection
-
Rated control supply voltage (DC):
-
24 - 240
-
Rated control supply voltage (AC 50Hz):
-
24 - 240
-
Rated control supply voltage (AC 60Hz):
-
24 - 240
