Silver inline oiling tool 1/4" model 10820-ST-03, MPN 10820-ST-03

Silver inline oiling tool 1/4" model 10820-ST-03 is a compact through-flow lubricator designed to deliver a controlled oil feed directly into pneumatic lines and machinery with 1/4" connections. The device installs in-line and allows continuous or intermittent lubrication of fittings, valves and moving parts, reducing friction and wear in workshop and industrial environments. Its straightforward design supports maintenance tasks where a regulated supply of lubricant is required without complex plumbing.

Advantages

The inline oiling tool provides precise metering of lubricant flow to target components, helping to maintain consistent lubrication levels. Its compact construction simplifies installation in confined spaces and minimizes pressure drop in the line. The tool is compatible with standard 1/4" pneumatic fittings and is suitable for retrofit or new installations where a reliable oil supply is needed. Materials and machining provide stable performance under typical workshop conditions.

Suitable for

• Lubrication of pneumatic valves and actuators in workshops and production lines
• Supply of oil to joints, bearings and moving mechanisms in industrial assemblies
• Maintenance stations and service benches that require inline lubrication with 1/4" connections
• Retrofit projects where a compact, through-flow oiling solution is needed

Key specifications

• Connection size: 1/4" inline fittings
• Type: through-flow inline lubricator
• Application: oil feed for pneumatic systems and mechanical moving parts
• Form factor: compact, inline mounting suitable for confined spaces
• Control: adjustable or metered oil delivery (where applicable by model design)

How to use

Install the oiling tool in the pneumatic or lubricant line using compatible 1/4" fittings, ensuring correct flow direction. Fill or connect the lubricant supply according to workshop procedures and set the delivery rate as needed for the target components. Verify system pressure and perform initial adjustments during a test run to confirm appropriate oil feed without over-lubrication. Regularly inspect the unit and refill or service according to operating intervals.

Usage recommendations

Use lubricants recommended for pneumatic and mechanical systems; avoid oils that can cause residue buildup or react with system materials. Periodically check the oil metering and clean or replace the unit if flow becomes irregular. When installing, follow standard safety measures for pressurized systems and isolate the line before maintenance.
