Shape Gauge Silver 260 mm — Silver brand template for measuring and tracing contours

Silver Shape Gauge 260 mm is a flexible contour template designed to measure, trace and transfer complex shapes and profiles with a working span of up to 260 mm. The tool adapts to irregular edges and curves, allowing accurate replication of contours from wood, metal, tile and other materials. It is produced for general trade use under the Silver brand and intended for fitting, trimming and templating tasks where precise outline copying is required.

Advantages

The shape gauge holds configured profiles in place without constant manual measurement, reducing repeated marking errors. Its metal-linked design provides both stability and flexibility so that it follows intricate curves while maintaining the set contour. The 260 mm span offers a practical balance between reach and control for medium-sized templates, and the compact construction makes it easy to store and carry between job sites.

Suitable for

• Carpentry and cabinet making for cutting and fitting joinery
• Tiling and flooring where accurate edge profiles are needed
• Metalwork and sheet metal shaping for template transfer
• DIY home renovations and custom fitting of appliances

Key specifications

• Maximum span: 260 mm for contour measurement and transfer
• Material: linked metal segments providing flexibility and rigidity
• Adjustability: conforms to complex curves and irregular edges
• Portability: compact size suitable for on-site use and storage

How to use

Place the gauge against the surface or edge you want to copy and gently press the linked segments so the profile conforms to the contour. Lock or hold the configured shape in position, then transfer the outline onto the workpiece by tracing along the gauge with a pencil or marker. For longer transfers, periodically recheck the shape to ensure the profile remains consistent while moving the template along the workpiece.

Usage recommendations

For best results, clean contact surfaces of dust and debris before measuring, and use a fine pencil or scribe to record the outline. When tracing on fragile finishes, place a thin protective layer between the gauge and the surface to prevent scratching. Store the gauge flat or hung to avoid bending segments out of alignment.
