header-product Sourcing Proxxon MF 70 multi-tool, 100 W, AC 230 V, 5,000–20,000 OPM, green, height 370 mm, weight 7 kg

Sourcing Proxxon MF 70 multi-tool, 100 W, AC 230 V, 5,000–20,000 OPM, green, height 370 mm, weight 7 kg

Sourcing Proxxon MF 70 multi-tool 100 W Photo 1
Out of stock.
View similar!

Short description

The Sourcing Proxxon MF 70 is a compact multi-tool for drilling and other precision tasks. It runs from AC 230 V with 100 W input power and an idle oscillation rate from 5,000 to 20,000 OPM. The unit is finished in green, stands 370 mm high and weighs 7 kg. Suitable for workshop and hobby use where controlled speed and stable power are required.
Warranty: 2 Years
SKU: 11225795
Manufacturer: Sourcing
delivery
Information regarding the items availability for purchase will be posted on this site
price
Item cost information will be published on this site
Together cheaper
{{product.price | formatAmount}}
{{product.title}}
{{productBundle.reference.specialPrice | formatAmount}}
{{productBundle.title}}
{{productBundlePreviousPrice | formatAmount}}
{{productBundleSpecialPrice | formatAmount}}

You saving {{productBundleYouSave | formatAmount}}

Product information

Description

The Sourcing Proxxon MF 70 is a compact precision miller designed for delicate projects and work with extremely small cutters. It features a stable grey-cast iron machine base, a vertical guide and a compound table, providing a rigid platform for accurate machining. The die-cast aluminium arm housing contains a balanced 24-pin special motor for vibration-free operation at high spindle speeds.

Advantages

Spindle speeds adjustable from 5,000 to 20,000 rpm allow controlled machining of small parts and cutters. The machine base and readjustable dovetail gib on all axes eliminate play and improve repeatability. Triple-slit hardened steel collets accommodate a range of small shank diameters, and the table with three T-slots follows the MICROMOT norm for secure fixturing.

Suitable for

  • Precision drilling and milling of small components
  • Hobby and model-making tasks requiring fine cutters
  • Workshop applications where compact, low-power milling is needed

Key specifications

  • Input power: 100 W
  • Supply voltage: AC 230 V
  • Spindle speed range: 5,000–20,000 rpm
  • Collet sizes (triple-slit hardened steel): 1 mm, 1.5 mm, 2 mm, 2.35 mm, 3 mm, 3.2 mm
  • Table: compound table with three T-slots (12 x 6 x 5 mm, MICROMOT norm)
  • Height: 370 mm
  • Weight: 7 kg
  • Housing: die-cast aluminium arm; base: grey-cast iron

How to use

Mount the appropriate MICROMOT collet for the cutter shank and secure the tool in the spindle. Set the desired spindle speed within the 5,000–20,000 rpm range according to cutter diameter and material. Position and clamp the workpiece on the table using the T-slots and the adjustable ruler scale to align the part. Use gradual feed rates and inspect the cutter periodically; ensure the machine is powered from a 230 V AC supply.

Usage recommendations

For best results with extremely small cutters, use low to medium spindle speeds, ensure the collet and cutter are clean and properly seated, and avoid excessive feed rates that can cause chatter. Maintain the dovetail gibs to eliminate play and check fixation in the T-slots before machining.

Specifications

Input power:
100 W
Weight:
7 kg
Multi-tool applications:
Drilling
Product colour:
Green
All features

Performance

Idle oscillation rate (min):
20000 OPM
Idle oscillation rate (max):
5000 OPM

Power

Power source:
AC
Input power:
100 W
AC input frequency:
50 - 60
AC input voltage:
230

Weight & dimensions

Weight:
7 kg
Height:
370 mm

Packaging content

Manual:
Yes

Features

Product colour:
Green
Multi-tool applications:
Drilling

Description
