StarTech.com USB-C to HDMI Adapter Cable 8K 60Hz 4K 144Hz

Chipset: Set of electronic components in an integrated circuit that manages the data flow between the processor, memory and peripherals. It is usually found in the motherboard of a computer. Chipsets are usually designed to work with a specific family of microprocessors. Because it controls communications between the processor and external devices, the chipset plays a crucial role in determining system performance.

VMM7100

Refresh rate at maximum resolution:

60 Hz

Converter type:

Active video converter

Supported audio channels:

7.1

USB Type-C DisplayPort Alternate Mode:

Yes

Logistics data

Products per master (outer) case:

160 pc(s)

Master (outer) case height:

420 mm

Master (outer) case length:

435 mm

Master (outer) case width:

415 mm

Packaging content

Quantity per pack:

1 pc(s)

Packaging data

Package weight: Weight of the packaged product.

64.5 g

Package height: The distance from the top to the bottom of the packaging.

12 mm

Package depth: The distance from the front to the back of the packaging.

220 mm

Package width: The distance from one side of the packaging to the other.

200 mm

Weight & dimensions

Cable diameter: The distance from one side of the cable to the other, with a straight line going through the middle of the cable.

4.8 mm

Weight: Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.

0.13 kg

Sustainability

Sustainability compliance:

Yes

Certificates

Compliance certificates: Indicates which regulatory, safety, and environmental standards the product complies with, as verified by recognized authorities or certification bodies.

CE, RoHS

Operational conditions

Operating relative humidity (H-H):

0 - 80

Storage temperature (T-T): The minimum and maximum temperatures at which the product can be safely stored.

0 - 75

Operating temperature (T-T): The minimum and maximum temperatures at which the product can be safely operated.

0 - 40

Features

Cable type: Type of cable e.g. electicity cable, optical cable.

Round cable

Plug and Play: Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration.

Yes

Dolby technologies:

Dolby Atmos, DTS:X

Maximum refresh rate:

144 Hz

High Dynamic Range (HDR) technology:

High Dynamic Range 10 (HDR10)

High Dynamic Range (HDR) supported:

Yes

Connector housing material:

Plastic

Jacket material:

Polyvinyl chloride (PVC)

HDCP: High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.

Yes

Supported graphics resolutions: The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.

7680 x 4320, 3840 x 2160, 2560 x 1440, 1920 x 1080 (HD 1080), 5120 x 1440

HDMI version:

2.1

Product colour: The colour e.g. red, blue, green, black, white.

Grey

Connector 2 form factor:

Straight

Connector 1 form factor:

Straight

HDCP version:

1.4/2.2/2.3

Maximum resolution: The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.

7680 x 4320

Connector 1 gender: The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.

Male

Connector 1: This is the first connector in the device.

USB Type-C

Cable length: How long the cable is.

1 m

Connector 2 gender: The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.

Male

Connector 2: This is the second connector in the device.

HDMI Type A (Standard)
