Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.0392 kg
-
Chipset:
Set of electronic components in an integrated circuit that manages the data flow between the processor, memory and peripherals. It is usually found in the motherboard of a computer. Chipsets are usually designed to work with a specific family of microprocessors. Because it controls communications between the processor and external devices, the chipset plays a crucial role in determining system performance.
-
Prolific - PL2303RA
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-20 - 100
-
Package weight:
Weight of the packaged product.
-
102.2 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 80
-
Cable length:
How long the cable is.
-
0.91 m
-
Relative humidity:
-
20 - 80
-
Height:
The measurement of the product from head to foot or from base to top.
-
16 mm
-
Width:
The measurement or extent of something from side to side.
-
45 mm
-
Depth:
The distance from the front to the back of something.
-
34 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Compatible operating systems:
List of desktop operating systems tested as compatible with this product.
-
Windows 7, 8.1, 10, 11
Windows Server 2016, 2019
macOS 10.11 to 10.15, 11.0, 12.0, Mac OS X 13.0 Ventura
Linux 4.15.x LTS Versions Only
Chrome OS
-
Package depth:
The distance from the front to the back of the packaging.
-
142 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
200 mm
-
Package width:
The distance from one side of the packaging to the other.
-
220 mm
-
Manual:
-
Yes
-
Master (outer) case height:
-
290 mm
-
Master (outer) case width:
-
570 mm
-
Connector 1:
This is the first connector in the device.
-
DB-9
-
Connector 2:
This is the second connector in the device.
-
USB Type-A
-
Baud rate:
-
921.6 Kbit/s
-
Data bits:
-
8, 7, 5, 6
-
Stop bits:
-
1, 1.5, 2
-
Parity bit:
-
Odd, Even, Mark, No, Space
-
Flow Control type:
-
DTR/DSR, No, RTS/CTS, XON/XOFF
-
FIFO (First In, First Out):
-
512
-
USB version:
Universal Serial Bus (USB) is an industry standard developed in the mid-1990s that defines the interface used for connection, communication and power supply between computers and electronic devices. Every new version - for example 1.1, 2.0, 3.0 - is much faster than the previous one.
-
2.0
-
Connector 1 form factor:
-
Straight
-
Connector 2 form factor:
-
Straight
-
Connector 1 gender:
The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.
-
Male
-
Connector 2 gender:
The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.
-
Male
-
Master (outer) case length:
-
355 mm
-
Products per master (outer) case:
-
100 pc(s)
-
Sustainability certificates:
-
CE, RoHS
