Converter type:
-
Passive video converter
-
Plug and Play:
Indicates whether this product supports is "plug and play". Plug and play is hardware or software that, after being installed ("plugged in"), can immediately be used ("played with"), as opposed to hardware or software which requires configuration.
-
Yes
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
HBR2 support:
-
Yes
-
Maximum refresh rate:
-
60 Hz
-
Supported graphics resolutions:
The graphic resolutions that can be displayed by the device. The graphic resolution describes the width and height dimensions of a display, such as a computer monitor, measured in pixels.
-
640 x 480 (VGA), 1920 x 1200 (WUXGA), 1920 x 1080 (HD 1080), 1680 x 1050 (WSXGA+), 1600 x 600, 1440 x 900, 1400 x 1050 (SXGA+), 1366 x 768, 1280 x 960, 1280 x 800 (WXGA), 1280 x 768 (WXGA), 1280 x 720 (HD 720), 1280 x 1024 (SXGA), 1152 x 864 (XGA+), 1024 x 768 (XGA), 800 x 600 (SVGA), 1360 x 768 (WXGA)
-
Supported video modes:
The video modes that can be displayed by the device.
-
1080p, 720p, 480p
-
Maximum resolution:
The maximum number of pixels that can be displayed in the image. It is usually quoted as width × height,: for example, "1024 × 768" means the width is 1024 pixels and the height is 768 pixels.
-
1920 x 1200
-
Dual Link DVI:
A dual-link DVI interface sends data over both of the DVI links to the monitor, and this is how higher resolutions are achieved. With dual-link DVI, a resolution of 2048 x 1536 is possible.
-
No
-
DisplayPort version:
-
1.2
-
HDCP version:
-
1.4
-
HDCP:
High-bandwidth Digital Content Protection (HDCP) is a form of digital copy protection to prevent copying of digital audio and video content as it travels across connections.
-
Yes
-
Connector 2 form factor:
-
Straight
-
Connector 1 form factor:
-
Straight
-
Connector 2 gender:
The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.
-
Female
-
Connector 1 gender:
The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.
-
Male
-
Connector 2:
This is the second connector in the device.
-
DVI-I
-
Connector 1:
This is the first connector in the device.
-
DisplayPort
-
Cable length:
How long the cable is.
-
0.152 m
