Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.3 kg
-
Mean time between failures (MTBF):
Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism.
-
282713.5 h
-
Operating relative humidity (H-H):
-
5 - 95
-
Chipset:
Set of electronic components in an integrated circuit that manages the data flow between the processor, memory and peripherals. It is usually found in the motherboard of a computer. Chipsets are usually designed to work with a specific family of microprocessors. Because it controls communications between the processor and external devices, the chipset plays a crucial role in determining system performance.
-
FTDI - FT4232HL
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-20 - 85
-
Package weight:
Weight of the packaged product.
-
518 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 55
-
Ports quantity:
The number of ports or external interfaces to which other equipment can be connected.
-
4
-
Height:
The measurement of the product from head to foot or from base to top.
-
23 mm
-
LED indicators:
-
Activity
-
Width:
The measurement or extent of something from side to side.
-
59 mm
-
Depth:
The distance from the front to the back of something.
-
1788 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Cables included:
-
USB
-
Host interface:
Interface that enables a host controller to communicate with a driver.
-
USB 2.0 Type-B
-
RS-232 ports:
The number of sockets (ports) for RS-232. An RS-232 serial port was once a standard feature of a personal computer, used for connections to modems, printers, mice, data storage, uninterruptible power supplies, and other peripheral devices. Now it has been largely replaced by USB and other ports.
-
4
-
Package depth:
The distance from the front to the back of the packaging.
-
152 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
50 mm
-
Package width:
The distance from one side of the packaging to the other.
-
216 mm
-
Manual:
-
Yes
-
Master (outer) case height:
-
264 mm
-
Master (outer) case width:
-
432 mm
-
Housing material:
What the casing of the product is made of.
-
Steel
-
Drivers included:
-
Yes
-
Baud rate:
-
921.6 Kbit/s
-
Data bits:
-
7, 8
-
Stop bits:
-
1, 2
-
Parity bit:
-
Even, Mark, No, Odd, Space
-
Windows operating systems supported:
Windows vesions wich can be used with the device.
-
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 2000, Windows 2000 Professional, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows CE, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows Vista x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
-
Mac operating systems supported:
Mac operating systems e.g. OS X can be used with the device.
-
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 13.0 Ventura
-
Linux operating systems supported:
8 RT. Linux (9.4, 9.5), Red Hat Enterprise Linux 5.0 (supported with a pre-built package); SUSE Linux (10.3, 11.0, 11, 11.1, 11.2), Fedora (9, 9.0, 10, 10.0, 11.0, 11, 12, 12.0), Ubuntu (8.04, 8.04.1, 8.04.2, 8.10, 9.04, 9.10, 10.04), Debian (5.0, 5.0.1, 5.0.2, 5.0.3)
-
Yes
-
Server operating systems supported:
-
Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
-
Other operating systems supported:
-
Windows XP Embedded
-
Power source type:
What the power source is.
-
USB
-
FIFO (First In, First Out):
-
256
-
Hub interfaces:
A hub is a device for connecting multiple devices together. The hub interface is where the hub connects to other devices via input/output (I/O) ports.
-
Serial
-
Power plug type:
-
Type M
-
Quantity per pack:
-
1 pc(s)
-
Master (outer) case length:
-
518 mm
-
Products per master (outer) case:
-
25 pc(s)
-
Harmonized System (HS) code:
-
84719000
-
DIN rail kit included:
-
Yes
-
Sustainability compliance:
-
Yes
-
Sustainability certificates:
-
CE, RoHS
