Weight:
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
-
0.18 kg
-
Storage temperature (T-T):
The minimum and maximum temperatures at which the product can be safely stored.
-
-20 - 85
-
Package weight:
Weight of the packaged product.
-
390 g
-
Operating temperature (T-T):
The minimum and maximum temperatures at which the product can be safely operated.
-
0 - 55
-
Cable length:
How long the cable is.
-
1.8 m
-
Relative humidity:
-
5 - 95
-
Height:
The measurement of the product from head to foot or from base to top.
-
23 mm
-
Input voltage:
The voltage (V) which is required to power the product.
-
5
-
Data transfer rate:
Rate at which data can be transferred. Usually expressed in units per second. May vary with network configurations.
-
0.0009 Gbit/s
-
Width:
The measurement or extent of something from side to side.
-
64 mm
-
Depth:
The distance from the front to the back of something.
-
118 mm
-
Product colour:
The colour e.g. red, blue, green, black, white.
-
Black
-
Cables included:
-
USB
-
Compatible operating systems:
List of desktop operating systems tested as compatible with this product.
-
Windows CE (4.2, 5.0, 6.0), XP Embedded, 98SE, 2000, XP, Vista, 7, 8, 8.1, 10, 11
Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016, 2019
macOS 10.6 to 10.15, 11.0, 12.0, 13.0
Linux Kernel 3.0.x+
-
Package depth:
The distance from the front to the back of the packaging.
-
230 mm
-
Package height:
The distance from the top to the bottom of the packaging.
-
160 mm
-
Package width:
The distance from one side of the packaging to the other.
-
45 mm
-
Master (outer) case height:
-
511 mm
-
Master (outer) case width:
-
502 mm
-
Connector 1:
This is the first connector in the device.
-
USB B
-
Connector 2:
This is the second connector in the device.
-
RS-422/485
-
Connector 1 gender:
The gender of the first connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the part bearing one or which fits into another being called male.
-
Male
-
Connector 2 gender:
The gender of the second connector of the product. Each half of a pair of mating connectors is assigned the designation male or female, the indented one or the one fitting around the other being called female.
-
Female
-
Quantity per pack:
-
1 pc(s)
-
Master (outer) case length:
-
400 mm
-
Products per master (outer) case:
-
50 pc(s)
