Drill Rotor for TRYTON TDW550 Impact Drill — Replacement Rotor YTDW01WS (16)

Replacement motor rotor designed specifically for the TRYTON TDW550 impact drill. This rotor restores the rotating element of the motor assembly and is intended for repair or refurbishment of the TDW550 when the original rotor, bearings, or windings are worn or damaged. The component fits into the existing motor housing and works with the drill’s stator and brushes to re-establish reliable rotational motion.

Advantages

This rotor is manufactured to match the dimensional and functional requirements of the TDW550 motor assembly, enabling straightforward replacement without modification to the housing or drive components. Using a correct-fit rotor helps recover the drill’s original rotational balance and reduces vibrations caused by worn parts. The part is suitable for restoring motor performance and extending the service life of the tool when installed as part of a standard motor refurbishment.

Suitable for

• Repair and refurbishment of TRYTON TDW550 impact drills
• Replacement of damaged or worn motor rotors and bearings
• Workshop maintenance and tool servicing
• DIY repairs by experienced users familiar with power tool motors

Key specifications

• Compatibility: TRYTON TDW550 impact drill motor assemblies
• Function: rotating armature for electromagnetic motor
• Construction: laminated rotor core with shaft for bearing mounting
• Fitment: designed for direct installation into original motor housing
• Intended use: repair, refurbishment, and replacement of worn motor components

How to use

Before installation, disconnect the drill from power and remove any battery packs or power cords. Disassemble the drill according to the manufacturer’s service instructions to access the motor assembly, noting brush and bearing positions for correct reassembly. Remove the old rotor by extracting retaining clips or screws and withdrawing the rotor shaft from the bearings. Install the replacement rotor by aligning the shaft and seating it in the bearings, then reattach retaining hardware, brushes, and covers in their original positions. After reassembly, check rotor clearance and bearing play by manually rotating the shaft before powering the tool.

Usage recommendations

Use this rotor only with compatible TRYTON TDW550 models. Inspect bearings, brushes, and commutator surfaces during replacement and replace worn ancillary parts to ensure balanced operation and prevent accelerated wear. If unsure about disassembly or motor servicing, consult a qualified technician or authorized service center.
